PUBLIC ADDRESS MIXING AMPLIFIER
5
PA-206/212/224
Front Panel
Front Panel
1. USB SLOT
Please use your own with adjustment the volume using each input volume and master volume, the tone using
the tone control.
2. USB PLAY MODE SELECTION BUTTON
1) ■ Button: Press the button to stop the audio file currently being played.
2) ▶|| Button: Press the button to play or pause the audio file.
When LED is turned on (by pressing the button once): Current audio file is played.
When LED blinks (by pressing the button twice): The audio file which is currently being played is paused.
3) |◀◀Button: Press the button briefly to move to the previous audio file. Press and hold the button for
more than 2 seconds to rewind.
4) ▶▶| Button: Press the button briefly to move to the next audio file. Press and hold the button for more
than 2 seconds to fast forward.
5) REPEAT Button: Press the button to play the audio file repeatedly.
①When Led is turned off: All audio files are played repeatedly.
②When LED is turned on (by pressing the button once): Those files stored in the folder with currently
playing audio file are played repeatedly.
③When LED blinks (by pressing the button twice): Only the currently playing audio file is played
repeatedly.
3. INPUT SIGNAL INDICATOR
If there is an input signal to INPUT 1~6, due input signal indicator lights up.
1 2 3 14 12 1113
4
5 6 87 9 10
Support file systems The maximum number of playable files
FAT16 512 Files
FAT32 65535 Files
NTFS Not Supported
OUTPUT 5V 0.5A
