PA-2312
P
UBLIC ADDRESS 2 CH POWER AMPLIFIER
Connecting Speakers
Connecting Speakers
Before connecting speakers to your PA-2312 unit, be sure to disconnect the AC power cable. Make certain that
t
he total impedance is not less than the rated impedance indicated.
For 4 speakers, connect the positive (+) connector to the 22V(4) terminal and the negative (–) connectors to
the COM terminal.
For high-voltage distributed systems, connect with matching transformer to the COM and either 70V or 100V
terminals. Be certain that the total impedance does not equal less than the rated impedance.
OUTPUT
CH 1
CH 2
COM
OUTPUT
CH 1
CH 2
- USA/CANADA & Associated Version
- EC & Associated, JAPAN Version
