PUBLIC ADDRESS AMPLIFIER
10
PA-612/624
PA-612 PA-624
Rated Output Power 120W 240W
Frequency Response 100Hz ~ 18kHz
T.H.D
(RMS output power, 1kHz, 20kHz LPF)
Less than 1%
High Pass Filter (400Hz) -3dB
S/N (20kHz LPF, A-WTD) Better than 80dB
Input Sensitivity/Impedance 1V/10k BAL
Output Voltage/Impedance
EC/JAPAN 4Ω/22V, 41Ω/70V, 83Ω/100V 4Ω/31V, 21Ω/70V, 42Ω/100V
USA/CANADA 4Ω/22V, 41Ω/70V 4Ω/31V, 21Ω/70V
Operation Temperature -10°C ~ +40°C
Power Source 100 - 120VAC or 220 - 240VAC; 50/60Hz
Power Consumption 40W(1/8 power) 65W(1/8 power)
Weight (SET) 8.9kg/19.6lb
Dimensions (SET) 482(W)x88(H)x380(D)mm/19(W)x3.5(H)x15(D)in
* Specifications and design subject to change without notice.
Specifications
Specifications
PA-612_624_E_PA-612_624_E 10. 7. 13. 오후 6:20 페이지 13
