Ref. Part No. Description Value
3
R38 R54-55 104294 RES,MF,270,1/5W,5%,AX N,TA 270
R39-40 R86 104306 RES,MF,33,1/5W,5%,AX N,TA 33
R41 R92 104616 RES,MF,270,2W,5%,RA R,TA 270 2W
R42 104668 RES,MF,4.7,2W,5%,RA R,TA 4.7 2W
R43 R52-53 R89 104329 RES,MF,470,1/5W,5%,AX N,TA 470
R44 104332 RES,MF,4.7K,1/5W,5%,AX N,TA 4.7K
R45 104316 RES,MF,390,1/5W,5%,AX N,TA 390
R46-47 104532 RES,MF,1K,2W,5%,RA R,TA 1K 2W
R48-49 104279 RES,MF,22,1/5W,5%,AX N,TA 22
R50-51 104273 RES,MF,200,1/5W,5%,AX N,TA 200
R56 R59 104281 RES,MF,2.2K,1/5W,5%,AX N,TA 2.2K
R57-58 104275 RES,MF,20K,1/5W,5%,AX N,TA 20K
R70 104174 RES,MF,9.09K,1/5W,1%,AX N,TA 9.09K 1%
R71 104347 RES,MF,56K,1/5W,5%,AX N,TA 56K
R72 104369 RES,MF,75K,1/5W,5%,AX N,TA 75K
R74 104136 RES,MF,3.24K,1/5W,1%,AX N,TA 3.24K 1%
R75 104120 RES MF 1.2K 1/8W FN 1.2K 1%
R76 104173 RES,MF,8.66K,1/5W,1%,AX N,TA 8.66K 1%
R82 104580 RES,MF,20,2W,5%,RA R,TA 20 2W
R83 R90 104236 RES,MF,1K,1/5W,5%,AX N,TA 1K
R84 R87 104361 RES,MF,6.8K,1/5W,5%,AX N,TA 6.8K
R85 104374 RES MF 820K 1/8W J N 820K
R88 104282 RES CF 22K 1/5W J N 22K
RLY11 112629 RELAY 897P-1AH-D T01(DC24V)S.C 897P-1AH-D
SVR11-12 105325 RES SEMI FT-63 TP(100) 100
TH11-12 103445 THERMIST,NTC,50OHM,125C TH50
TP11-15 112218 CNT PLUG 1P CNT-01P
U11 U14 102816 IC,OP AMP,NJM4558D,DIP8 4558D
U12 102888 IC,OP AMP,NJM4580D,DIP8 4580D
U13 103063 IC,VOLT REG,15V,1A,MC7815CTG,TO-220AB 7815
ZD11 102725 DIODE,ZN,500MW,BM,7.5V,DO-35,TA 7.5B
ZD12 ZD18 102742 DIODE,ZN,500MW,BM,16V,DO-35,TA 16BM
ZD13 102733 DIODE,ZN,500MW,BM,8.2V,DO-35,TA 8.2BM
ZD14 102735 DIODE,ZN,500MW,BM,10V,DO-35,TA 10BM
ZD15-16 102731 DIODE,ZN,500MW,BM,5.6V,DO-35,TA 5.6BM
ZD17 102737 DIODE,ZN,500MW,BM,12V,DO-35,TA 12BM
ZD19 102748 DIODE,ZN,500MW,BM,24V,DO-35,TA 24BM
ZD20 102770 DIODE,ZN,1W,BM,10V,DO-41,TA 10V 1W
ZD21 102767 DIODE,ZN,1W,BM,12V,DO-41,TA 12V 1W
AN13 108157 CON ASS'Y 4P 210MM ASS'Y-04P
C101 C103 105396 CAP,E,SM,SE,85C,10UF,50V,M,6.3X5,TA 10/50
C102 105448 CAP,E,SM,SE,85C,1UF,50V,M,4X5,TA 1/50
C104 105511 CAP,E,SM,SG,85C,47UF,50V,M,6P,TA 47/50
C105-106 105546 CAP,E,SM,SE,85C,4.7UF,50V,M,TA 4.7/50
C107 124025 CAP,E,SM,SRE,85C,22UF,50V,M,5P,TA 22/50
CR101 122492 CAP,CE,TEMP,SL,10PF,50V,J,AX,TA 10P
CR102-103 105777 CAP CE Y 100000PF 50V Z AXIAL 0.1U
D101 102687 DIODE,SW,100MA,75V,1N4148M,DO-34M,TA 1N4148
LD101-102 103244 LED,RND 3MM,RED,CLR,1U,AN5,TA ML3BHD2F-EAA-T
LD103-104 103245 LED,RND 3MM,GRN,CLR,1U,AN5,TA LTL-1CHGE-021A
R101 R104 104270 RES,MF,18K,1/5W,5%,AX N,TA 18K
R102 104309 RES,MF,33K,1/5W,5%,AX N,TA 33K
R103 104372 RES,MF,8.2K,1/5W,5%,AX N,TA 8.2K
R105 104236 RES,MF,1K,1/5W,5%,AX N,TA 1K
R106 R108 R123 104238 RES,MF,100K,1/5W,5%,AX N,TA 100K
ELECTRICAL PARTS LIST
LED DRIVER B'D
