Ref. Part No. Description Value
ELECTRICAL PARTS LIST
4
R107 104176 RES MF 9.4K 1/8W F N 9.4K 1%
R109 104317 RES,MF,3.9K,1/5W,5%,AX N,TA 3.9K
R110 104281 RES,MF,2.2K,1/5W,5%,AX N,TA 2.2K
R111 104371 RES,MF,820,1/5W,5%,AX N,TA 820
R112 104185 RES,MF,220,1/5W,1%,AX N,TA 220 1%
R113 104239 RES,MF,1M,1/5W,5%,AX N,TA 1M
R114-115 104361 RES,MF,6.8K,1/5W,5%,AX N,TA 6.8K
R116-121 104274 RES,MF,2K,1/5W,5%,AX N,TA 2K
R122 104332 RES,MF,4.7K,1/5W,5%,AX N,TA 4.7K
R124 104256 RES,MF,1.5K,1/5W,5%,AX N,TA 1.5K
R125 104237 RES,MF,10K,1/5W,5%,AX N,TA 10K
R126 104363 RES,MF,680K,1/5W,5%,AX N,TA 680K
Q101 102528 TR,SG,NPN,100MA,120V,KTC3200BL,TO-92,TA KTC3200-BL
Q102 Q104-105 102525 TR,SG,NPN,150MA,50V,KTC3198Y,TO-92,TA KTC3198-Y
Q103 102544 TR,SG,NPN,700MA,50V,2SD1111-AA 2SD1111
U101-102 102816 IC,OP AMP,NJM4558D,DIP8 4558D
ZD101 102734 DIODE,ZN,500MW,BM,9.1V,DO-35,TA 9.1B
ZD102-103 102737 DIODE,ZN,500MW,BM,12V,DO-35,TA 12BM
R91 104719 RES,CE,WW,100,5W,5%,RA T 100 5W
T1 111895 TERMINAL,SCREW,4P,10MM,ST TERMINAL04P
TP2 112218 CNT PLUG 1P CNT-01P
C35-36 105865 CAP,FILM,POLYSTR,0.047UF,400,J 0.047/400(M)
CN18 110411 WAFER LW(3.96) 5P JIS WAFER
SP1 105670 CAP,CE,HI-DI,0.01UF,500V,Z,RA,TA 0.01/500
J1 J3 J6 102394 JUMP WIRE JUMPER(DOM. etc.)
J2 J4/1 J4/2 J6 102394 JUMP WIRE JUMPER(UL/CSA)
AN1 107834 CON ASS'Y 6P SHIELD #26 CON ASS'Y 6P SHIELD
BKT1 113528 BRACKET PCB PS-A152 BRACKET
BKT2 113464 BRACKET PHONE JACK B BRACKET
C1 105480 CAP,E,SM,SG,85C,0.22UF,50V,M,5P,TA 0.22/50
C2 105537 CAP,E,SM,SG,85C,0.47UF,50V,M,5P,5,TA 0.47/50
C3 105820 CAP,FILM,POLYSTR,0.01UF,100V,J,TA 0.01/100(M)
C5-6 105624 CAP,E,LA,15000UF,63V,M,35*50 15000/63
DC1 111590 TERMINAL,DC,2P,19MM,AN,V-0 TERMINAL02P
F15 111858 FAU-0031.3577 SCHURTER PU-3210 FH-FAU0031.3577
H1 107861 CON ASS'Y 1P WHT TUBE 250-TER ASS'Y 1P WHT TUBE
H2 107863 CON ASS'Y 1P BLK TUBE 250-TER ASS'Y 1P BLK TUBE
H3 107838 CON ASS'Y 1P RED TUBE 250-TER ASS'Y 1P RED
H4 108155 CON ASS'Y 1P BLK TUBE 250-TER ASS'Y 1P BLK TUBE
H7 108156 CON ASS'Y 1P BLUE CON ASS'Y 1P BLUE
H15 107839 CON ASS'Y 1P RED TUBE 250-TER ASS'Y 1P RED TUBE
H16 107864 CON ASS'Y 1P BLK TUBE 250-TER ASS'Y 1P BLK TUBE
JK1 111675 JACK,XLR(F),1U,3P,AN XLR/F
JK2 110898 JACK,XLR(M),1U,3P,AN,E403A0090N XLR/M
P3-6 P9-10 P19-P21 111903 TERMINAL(250)PCB TAB 250T
R1 104308 RES,MF,3.3K,1/5W,5%,AX N,TA 3.3K
SW1-2 111948 SW,SLIDE,HOR,DPDT,NS,L7.5 SV10020
VR1 105193 VR,ROT,HOR,1U,L25,5K,B 5KB
AN2 124007 CON ASS'Y,FL,2P,5264,51088,230MM ASS'Y-02P
C4 105789 CAP,CE,AC,Y2/X1,0,01UF,250VAC,M,RA 0.01/250
SW3 112157 SW POWER JPP 2197BCS32 JPP 2197BCS32
TERMINAL B'D
JACK B'D
POWER S/W B'D (PW SW B'D)
To Next Page
