PUBLIC ADDRESS AMPLIFIER
16
PAM-120A/340A/480A
Specifications
Specifications
PAM-120A PAM-340A PAM-480A
Rated Output Power 120W (RMS):THD 1% 340W (RMS):THD 3% 480W (RMS):THD 3%
Frequency Amp In 80Hz~20kHz
Response Link In 80Hz~15kHz
CH1~CH6 120Hz~8kHz
Remote In - 120Hz~8kHz 120Hz~8kHz
T.H.D.(at 1kHz Rated Output) Less than 1% - -
T.H.D.(at 1kHz Half Power Output) - Less than 0.5% Less than 0.5%
S/N Amp In Better than 90dB Better than 88dB Better than 88dB
Link In Better than 65dB
CH1~CH6 Better than 50dB
Remote In - Better than 50dB Better than 50dB
Input CH1~CH6
Sensitivity/
TRIM VR -60dB Position 1mV/10kΩ
Impedance TRIM VR -16dB Position 158mV/10kΩ
Link In 100mV/10kΩ
Amp In 1V/47kΩ 1V/20kΩ 1V/20kΩ
Remote In - 1V/10KΩ 1V/10KΩ
Speaker Output/Impedance 120W/4Ω ,70V/42Ω,100V/83Ω 340W, 100V/29.4Ω 480W, 100V/20.8Ω
Preamp Output/Impedance 1V/600Ω
Tone Control (100Hz, 10kHz) ±12dB
CH1~CH6 EQ Control (100Hz, 1kHz, 10kHz) ±12dB
Operation Temperature 14F~104F (-10°C~+40°C)
Power Source 100–120VAC or 220V–240VAC; 50/60Hz, 24V DC(only PAM-120A)
(Supplied AC mains transformer depends on country requirements)
Power Consumption 135W(1/8 POWER) 260W(1/8 POWER) 360W(1/8 POWER)
200W(1/3 POWER) 400W(1/3 POWER) 550W(1/3 POWER)
300W(FULL POWER) 620W(FULL POWER) 880W(FULL POWER)
Weight 13kg/28.7lb 13.5kg/29.7lb 15.5kg/34.2lb
Dimensions 420(W) x 132(H) x 360(D)mm/16.5(W) x 5.2(H) x 14.2(D)in
* Specifications and design subject to change without notice.
