Inter-m PAM-510 - Specifications

Amplifier Section Rated Output Power (THD 1%) 120W(RMS) 240W(RMS)
(Amp In@1kHz,
Speaker Zone 1~5 Output 25W MAX 50W MAX
4Ω Load Output)
Input Sensitivity/Impedance 1V/20kΩ
S/N Better than 85dB
Frequency Response
80Hz~18kHz
(at 1kHz Half Power Output, ±3dB)
Mic Input Section Input Sensitivity/Impedance –60dBV/600Ω
(Mic 1~4 In@1kHz,
S/N Better than 55dB
Preamp Out)
Frequency Response (±3dB) 120Hz~10kHz
Tone Control (Bass:100Hz,Treble:10kHz)
±12dB
Phantom Power +24VDC
Line Input Section Input Sensitivity/Impedance –30dBV/10kΩ
(Line 1~2 In@1kHz,
S/N Better than 65dB
Preamp Out)
Frequency Response (±3dB) 80Hz~15kHz
Tone Control (Bass:100Hz,Treble:10kHz) ±12dB
Remote Amp Section
Mic Input Sensitivity/Impedance –60dBV/600Ω
(Remote In@1kHz,
S/N Better than 55dB
Preamp Out)
Frequency Response (±3dB) 120Hz~10kHz
Tel In Section Input Sensitivity/Impedance 0.3V/600Ω(USA/Canada)
(Tel In@1kHz,
0.775V/600Ω(EC & Associated)
Preamp Out)
S/N Better than 65dB
Frequency Response (±3dB) 330Hz~3kHz
Pre Amp Out(Mic 1~4, Line 1~2, Tel In, Remote In) 0dBV/600Ω
T.H.D Less than 0.5%
Record Out –10dBV/3kΩ
Operating Temperature –10°C~40°C
Power Source
100–120VAC or 220–240VAC; 50/60Hz, 24VDC
Power Consumption (1/8 POWER) 180W 320W
Weight 17kg/37.6lb 19kg/42lb
Dimensions 482(W) x 132(H) x 398(D)mm
19(W) x 5.2(H) x 15.7(D)in
* Specifications and design subject to change without notice.
13
PAM-510/520
ATT. ZONE AMPLIFIER
Specifications
Specifications................................................................
*0dBV=1Vrms
PMA-510 PAM-520
