* 100V or 250V can be selected optionally.

* Pay attention than only high impedance terminal can be controlled by the speaker selector of front panel.

18. IMPEDANCE SELECTOR SWITCH

This switch is for selecting the high impedance.

PAM-60 : 165Ω (100V) or 83Ω (70V)

PAM-120 : 83Ω (100V) or 42Ω (70V)

19. (OPTION)

This terminal is for connecting the antenna terminal, when you can use the tuner.

(Our Model PAM-UNER)

Questions and Answers:

Need help?

Do you have a question about the Inter-m PAM-60 and is the answer not in the manual?

Inter-m PAM-60 Specifications

Electrical Specifications

rated output	60W (RMS)
input sensitivity/impedance	1mV-160mV/600Ω
frequency response	80Hz~20KHz
T.H.D (at 1KHz rated output)	Less than 1%
S/N	Better than 100dB
tone control (100Hz, 10KHz)	12dB
EQ control (100Hz, 1KHz, 10KHz)	12dB
speaker output/impedance	60W (4Ω), 83Ω (70V), 165Ω (100V)
pre amp out/impedance	1V/600Ω
music on hold/impedance	0.775V/600Ω
link out/impedance	500mV/600Ω

General Specifications

Electrical Specifications

rated output	120W (RMS)
input sensitivity/impedance	1mV-160mV/600Ω
frequency response	80Hz~20KHz
T.H.D (at 1KHz rated output)	Less than 1%
S/N	Better than 100dB
tone control (100Hz, 10KHz)	12dB
EQ control (100Hz, 1KHz, 10KHz)	12dB
speaker output/impedance	120W (4Ω), 42Ω (70V), 83Ω (100V)
pre amp out/impedance	1V/600Ω
music on hold/impedance	0.775V/600Ω
link out/impedance	500mV/600Ω
