Electrical Specifications| rated output | 60W (RMS) |
|---|---|
| input sensitivity/impedance | 1mV-160mV/600Ω |
| frequency response | 80Hz~20KHz |
| T.H.D (at 1KHz rated output) | Less than 1% |
| S/N | Better than 100dB |
| tone control (100Hz, 10KHz) | 12dB |
| EQ control (100Hz, 1KHz, 10KHz) | 12dB |
| speaker output/impedance | 60W (4Ω), 83Ω (70V), 165Ω (100V) |
| pre amp out/impedance | 1V/600Ω |
| music on hold/impedance | 0.775V/600Ω |
| link out/impedance | 500mV/600Ω |
General Specifications| power source | AC 110V~240V, 50/60Hz, DC 24V |
|---|---|
| power consumption | 150W |
| weight | 11.4Kg |
| dimensions | 420(W) 132(H) 360(D) mm |
Electrical Specifications| rated output | 120W (RMS) |
|---|---|
| input sensitivity/impedance | 1mV-160mV/600Ω |
| frequency response | 80Hz~20KHz |
| T.H.D (at 1KHz rated output) | Less than 1% |
| S/N | Better than 100dB |
| tone control (100Hz, 10KHz) | 12dB |
| EQ control (100Hz, 1KHz, 10KHz) | 12dB |
| speaker output/impedance | 120W (4Ω), 42Ω (70V), 83Ω (100V) |
| pre amp out/impedance | 1V/600Ω |
| music on hold/impedance | 0.775V/600Ω |
| link out/impedance | 500mV/600Ω |
General Specifications| power source | AC 110V~240V, 50/60Hz, DC 24V |
|---|---|
| power consumption | 300W |
| weight | 13.5Kg |
| dimensions | 420(W) 132(H) 360(D) mm |
