PUBLIC ADDRESS MIXING AMPLIFIER
11
PU-103/106/112
Applications
Applications
TELEPHONE
INTERFACE
MUTE
CD PLAYER
PC
MIC
MIC
LOW IMPEDANCE
SPEAKER
(PU-103/106 : 8Ω)
(PU-112 : 4Ω)
(
-
)
(+)
※ IMPEDANCE SELECTION SWITCH OFF
※You have to select one between 4Ω/8Ω and High voltage output.
You never use both 4Ω/8Ω with High voltage output at the same time. Please use only one
output terminal. (4Ω/8Ω, 70V, 100V) If you do this system will have damaged or work
protection.
USING LOW INPEDANCE SPEAKER
