Inter-m PU-103 - Specifications

PUBLIC ADDRESS MIXING AMPLIFIER
14
PU-103/106/112
Specifications
Specifications
PU-103 PU-106 PU-112
Rated Output Power (1kHz, THD 1%)
15.5V(8Ω) 21.9V(8Ω) 21.9V(4Ω)
70V(166Ω) 70V(82Ω) 70V(40.83Ω)
100V(333Ω) 100V(167Ω) 100V(83.33Ω)
S/N
MIC 55dB
RCA, 6.35Φ PHONE JACK
55dB
LINE, TEL IN 55dB
Input Sensitivity
/Impedance
MIC (BALANCE) -60dBV /2kΩ
LINE (BALANCE) -20dBV /2kΩ
RCA (UNBALANCE) -20dBV /20kΩ
6.35Φ PHONE JACK
(UNBALANCE)
-20dBV /2kΩ
TEL IN (UNBALANCE) 0dBV/5kΩ
THD+N 1kHz (1/3Pwr @8Ω) Less than 1%
TONE CONTROL
BASS(200Hz) ±10dB
TREMBLE(15KHz) ±10dB
Frequency Response
(1W,±3dB,Low-Z)
INPUT 1~2 (MIC) 300Hz~12kHz
INPUT 2~3 (LINE), TEL IN 300Hz~15kHz
Operating Temperature
-10℃~+40℃
Power Source AC 120-240V, 50/60Hz
Power Consumption (1/8W) 20W 35W
Weight (Set) 2.82kg/6.2Ib 3.18kg/7.01Ib 3.18kg/7.01Ib
Dimensions (Set) 300(W) x 44(H) x 230(D)mm/11.8(W) x 1.7(H) x 9(D)in
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
