PUBLIC ADDRESS MIXING AMPLIFIER
6
PU-103/106/112
3. INPUT SIGNAL LED
These green LEDs flash when signal is present and the input level control to INPUT 1~3 is turned up.
4. INPUT VOLUME
These adjust the Mixing level of input signal of INPUT 1~3.
※You can adjust the volume of USB and AUX input through INPUT 3 volume.
5. TONE CONTROL
These controls the BASS (200Hz) and TREBLE (15kHz) of the main output signal by ±10dB.
6. MASTER VOLUME
This controls the main output level. Turn the master volume clockwise to increase volume.
7. POWER SWITCH, POWER LED
It is a power supply switch. After connecting the power cord on the back of the equipment, press the switch to
supply power to the equipment and turn on the power LED (Blue).
