17. FIRE ALARM CONTACT CLOSURE
Contact closures are provided for each of the eight zones. Emergency messages can be sent to any zone
preset to receive such messages.
- Remote Address Setup Legend
PIN Number
1
2
3
4
5
6
7
8
9
PIN NAME Functions
D-GND Shared ground port
Zone 8 CC Contact point input port for Zone 8
Zone 7 CC Contact point input port for Zone 7
Zone 6 CC Contact point input port for Zone 6
Zone 5 CC Contact point input port for Zone 5
Zone 4 CC Contact point input port for Zone 4
Zone 3 CC Contact point input port for Zone 3
Zone 2 CC Contact point input port for Zone 2
Zone 1 CC Contact point input port for Zone 1
