C302 C311 3409247131-T CAP AF SG 470UF 16V 10X12.5 470/16
C314 C461
C470 3409247973-T CAP RSE 4.7UF 50V (5*5)MX-200 4.7/50
C312 3409268872-T CAP AF RSS 0.68UF 50V 4 P 0.68/50
C438 C468 3509101231-A CAP CE B 100PF 50V K AXIAL 100P
C442 C447 3509151231-A CAP CE B 150PF 50V K AXIAL 150P
C427-C428 3509221231-A CAP CE B 220PF 50V K AXIAL 220P
C441
C303-C304 3509330130-T CAP CE SL 33PF 50V J 33P
C401-C404 3509331231-A CAP CE B 330PF 50V K AXIAL 330P
C413
C415-C416
C449
C412 C426 3509562530-T CAP CE F 0.0056UF 50V Z 0.0056
C443 C446 3509821231-A CAP CE YB 820PF 50V K AXIAL 820P
C306 3529103531-A CAP CE F 10000PF 50V Z 0.01
C434 -C435 3529220311-A CAP CE SL 22PF 50V J AXIAL 22P
C411 C425 3529560311-A CAP CE SL 56PF 50V J AXIAL 56P
C301 C305 3569104933-A CAP CE MONO 0.1UF 50VZSMA-4000 0.1
C454 3569104933-A CAP CE MONO 0.1UF 50VZSMA-4000 0.1/50
C308 C310 3609104122-T CAP MA 0.1UF 100V J SMALL 0.1(M)
C460 C462
C456 3609152120-T CAP MA 0.0015UF 100V J 0.0015(M)
C406 C418 3609153120-T CAP MA 0.015UF 100V J 0.015/100(M)
C453 3609153120-T CAP MA 0.015UF 100V J 0.015(M)
C455 C457 3609562120-T CAP MA 0.0056UF 100V 0.0056(M)
D651-D658 2058304100 DIODE IN4148M 1N 4148
D660
D659 2058500051 DIODE ZENER UZ-5.1B(4.8,5.4) UZ 5.1B
IC651-IC654 2118010590 IC NJM4558D JRC NJM 4558D
IC601 2118050129 IC M5289P MITSUBISHI M 5289P
R704 3004100953 RES CF 100 1/5W FN SMA-4000 100
R696 3009000973 RES CF 0 1/5W JN 0
R601-R602 3009101973 RES CF 100 1/5W J N 100
R664 R684 3009102973 RES CF 1K 1/5W J N 1K
R702-R703 3009105973 RES CF 1M 1/5W J N 1M
R705-R710
R653-R654 3009121973 RES CF 120 1/5W J N 120
R674 3009122973 RES CF 1.2K 1/5W J N 1.2K
R669 3009152973 RES CF 1.5K 1/5W J N 1.5K
R679 3009202973 RES CF 2K 1/5W J N 2K
R652 3009203973 RES CF 20K 1/5W J N 20K
R657 R662 3009222973 RES CF 2.2K 1/5W J N 2.2K
R667 R672
R677 R682
R687 R692
R689 3009272973 RES CF 2.7K 1/5W J N 2.7K
R650 3009302973 RES CF 3K 1/5W J N 3K
R658 R663 3009392973 RES CF 3.9K 1/5W J N 3.9K
R668 R673
R678 R683
R688
R605-R606 3009472973 RES CF 4.7K 1/5W J N 4.7K
R670 R675 3009473973 RES CF 47K 1/5W J N 47K
R680
R656 R661 3009562973 RES CF 5.6K 1/5W J N 5.6K
R666 R671
R676 R681
R686 R691
R660 R665 3009563973 RES CF 56K 1/5W J N 56K
R690
R659 3009681973 RES CF 680 1/5W J N 680
R655 R685 3009683973 RES CF 68K 1/5W J N 68K
R697-R698 3009821973 RES CF 820 1/5W J N 820
R651 3009823973 RES CF 82K 1/5W J N 82K
VR621 3228069930 VR RK09L1140A31 10KA 10KA
VR601- 3228070040 VR RS20111C600114W 100KW
VR607
C609 3609474122 CAP MA 0.47UF 100V MINI 0.47/100(M)
C616 3619361110 CAP PL 360PF 50V J 360(P)
C618 3619680110 CAP PL 68PF 50J 68(P)
AN602 4355980812 CON SHIELD ASS'Y 2P 250MM 2P
AN603 4355751911 CON ASS'Y 5P 230MM SYS2120 5P
AN601 4355752421 CON ASS'Y 6P 510MM SYS-2120 6P
Ref No. Part No. ValueDescription
R330 3009474973 RES CF 470K 1/5W J N 470K
R460 3009563973 RES CF 56K 1/5W J N 56K
R403 R423 3009680973 RES CF 68 1/5W J N 68
R487
R316 3009682973 RES CF 6.8K 1/5W J N 6.8K
R409 R431 3009683973 RES CF 68K 1/5W J N 68K
R323 R325 3009821973 RES CF 820 1/5W J N 820
R327 R407
R410 R433
R435
C450-C451 3619103210 CAP PL 10000PF 100V 0.01(P)
C452 3619332110 CAP PL 3300PF 50V J 3300P
X301 3908101090 RESONATOR CST 4.19MGW MURATA 11.0592MHz
AN304 4353979306 CON ASS'Y 07P 130MM 7P
AN401 4353979401 CON ASS'Y 09P 80MM 9P
AN507 4353981614 CON SHIELD ASS'Y 6P 300MM 6P
AN302- 4353982206 CON ASS'Y 10P 130MM 8P
AN303
AN405 4353982309 CON ASS'Y 4P 190MM 4P
AN305 4353983116 CON ASS Y 4P 360MM YAW025-05P
AN703
CN305
AN306 4353983210 CON ASS'Y 4P 210MM 4P
CN403 4355875603 CONN SOCKET 3P (PCB TO PCB) 3P
CN404 4355875606 CONN SOCKET 6P (PCB TO PCB) 6P
CN306 4428594904 LA5268/LAB0640/2.5MM-04P 4P
CN405
CN304 4428594907 LA5268/LAB0640/2.5MM-07P 7P
CN302-CN303
4428594908 LA5268/LAB0640/2.5MM-08P 8P
CN307 4428599311 WAFER 52004-1110 J.MOLEX 11P
CN308 4428599313 WAFER 52004-1310 J.MOLEX 13P
SW315 4618999910 SW SS65010-0203-9H-FN SSSJ823GB051
SW301- 4628985710 TACT (5MM) THVV501BAA (KBW89) 9MM SW
SW314
SW316
RY401 5528009960 RELAY RZ-12 RY-12W RZ-12
Q307 Q415 2008209100-T TR PNP MPSA56 MPSA 56
Q413 Q414 2008606100-T TR NPN KTC 200Y KEC KTC 200Y
Q405-Q406 2008606104-T TR NPN KTC 3198Y KTC 3198Y
Q304-Q306 2008606110-T TR NPN KRC 107M KEC KRC 107M
Q309 Q311
Q401
Q402-Q404
Q408
Q411-Q412
Q416 Q407
Q303 Q308 2008606113-T TR PNP KTA 1271(A1515) KEC KTA 1271
Q310
Q301-Q302 2008606998-T TR NPN KTD 1302 KEC ONLY 2SD 1302R
Q409-Q410
Q417-Q418
WR301 3039100572-F RES MO 10 2W J N 10 2W
WR401
WR302 3039330572-F RES MO 33 2W J N 33 2W
SVR301- 3248322220-T RES SEMI 2.2K N6L25T1N 2.2K
SVR302
C407-C408 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C410 C421
C424 C429
C431-C433
C436 C437
C439-C440
C445 C458
C466
C307 C309 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C419 C459
C315-C316 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50
C464-C465 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50
C420 C444 3409222971-T CAP AF RSG 2.2UF 50V 5 P 2.2/50
C448 C463
C313 3409233871-T CAP AF RSG 0.33UF 50V 5 P 0.33/50
C430 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25
C405 C409 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C414 C417
C422-C423
C467 C469
Ref No. Part No. ValueDescription
26
EQ B’D (4003483900)
CN604 4428596804 FLAT ANGLE WAFER FA-1143-04P 4P
CN706-
CN707
AN606 4428596805 FLAT ANGLE WAFER FA-1143-05P 5P
AN605 4428596807 FLAT ANGLE WAFER 7P 7P
SW622 4625996010 SW LEVER SL10020-0203-9P-SN SL10020
SW623 4628987810 SW PUSH SPEC122RC011 (SUK78) SW
R693 3039100572-F RES MO 10 2W J N 10 2W
R695 3039102572-F RES MO 1K 2W J N 1K 2W
R694 3039200572-F RES MO 20 2W J N 20 2W
C601-C602 3409210033-T CAP E SE 10UF 16V 4*5 10/16
C651-C652
C679
C654 C657 3409222873-T CAP E SE 0.22UF 50V 3*5 0.22/50
C660 C663
C666 C669
C672 C675
C603 C605 3409247033-T CAP E SE 47UF 16V 6.3*5 47/16
C676 C678
C604 3509681231-A CAP CE YB 680PF 50V K AXIAL 680P
C677 3529103531-A CAP CE F 10000PF 50V Z 0.01
C682-C683 3529104531-A CAP CE F 100000PF 50V Z 0.1
C680-C681 3529300311-A CAP CE SL 30PF 50V J AXIAL 30P
C614 3609102120-T CAP MA 0.001UF 100V 0.001/100(M)
C655-C656 3609152120-T CAP MA 0.0015UF 100V J 0.0015/100(M)
C608 C617 3609153120-T CAP MA 0.015UF 100V J 0.015/100(M)
C664-C665 3609223120-T CAP MA 0.022UF 100V J 0.022/100(M)
C612 3609252120-T CAP MA 0.0025UF 100V J 0.0025/100(M)
C658-C659 3609332120-T CAP MA 0.0033UF 100V 0.0033/100(M)
C615 3609393120-T CAP MA 0.039UF 100V J 0.039/100(M)
C667-C668 3609473120-T CAP MA 0.047UF 100V 0.047/100(M)
C606 3609563120-T CAP MA 0.056UF 100V 0.056/100(M)
C610 3609682111-T CAP ECQ-B 1H682JS4 PANASONIC 0.0068/100(M)
C619 3609822120-T CAP MA 0.0082UF 100V 0.0082/100(M)
C661-C662
C613 C653 3609823120-T CAP MA 0.082UF 100V J 0.082/100(M)
C607 3639105111-T CAP ECQ-V 1H105JL2 1UF 50V 1UF
C670-C671 3639124111-T CAP ECQ-V 1H124JL2 0.12UF 50V 0.12/100(M)
C611 3639224111-T CAP ECQ-V 1H224JL2 0.22UF 50VJ 0.22/100(M)
C673-C674
Q505 2008606104 TR NPN KTC1815Y (KTC3198) KTC 1815Y
D502 2058304100 DIODE IN4148M 1N 4148
D505-D507
D501 2058502056 DIODE ZENER UZ-5.6BM(5.4,5.8) UZ 5.6BM
D503-D504 2058502082 DIODE ZENER UZ-8.2BM(7.9,8.5) UZ 8.2BM
IC501-IC505 2118010432 IC NJM2068DD JRC NJM 2068DD
IC508-IC509
IC507 2128514003 IC NJU4066BD JRC GD4065
IC506 2128740208 IC BXA 4240 BXA4240K
FB511-FB512
2648609900 FERITE BEAD H5B FB
FB521-FB522
FB531-FB532
FB541-FB542
FB551-FB552
R565 3003499953 RES CF 4.99K 1/5W F N 4.99K 1%
R559 R602 3009000973 RES CF 0 1/5W JN 0
R610-R619
R561 R563 3009101973 RES CF 100 1/5W J N 100
R585 R608
R592-R593 3009102973 RES CF 1K 1/5W J N 1K
R501 R505 3009103973 RES CF 10K 1/5W J N 10K
R511-R512
R521-R522
R531-R532
R541-R542
R551-R552
R570 R573
R576
R506-R507 3009104973 RES CF 100K 1/5W J N 100K
R539 R587
R594 R596
R503 3009105973 RES CF 1M 1/5W J N 1M
R579 3009113973 RES CF 11K 1/5W J N 11K
R502 R600 3009123973 RES CF 12K 1/5W J N 12K
R519 R572 3009133973 RES CF 13K 1/5W J N 13K
R590
R528 3009152973 RES CF 1.5K 1/5W J N 1.5K
R510 R520 3009153973 RES CF 15K 1/5W J N 15K
R530 R540
R550 R568
R569 R571
R581
R583 3009182973 RES CF 1.8K 1/5W J N 1.8K
R508 3009223973 RES CF 22K 1/5W J N 22K
R582 3009225973 RES CF 2.2M 1/5W J N 2.2M
R504 3009274973 RES CF 270K 1/5W J N 270K
R598 3009302973 RES CF 3K 1/5W J N 3K
R549 3009333973 RES CF 33K 1/5W J N 33K
R589 3009334973 RES CF 330K 1/5W J N 330K
R574 3009392973 RES CF 3.9K 1/5W J N 3.9K
R562 R564 3009393973 RES CF 39K 1/5W J N 39K
R584 R609
R527 R586 3009473973 RES CF 47K 1/5W J N 47K
R591 R595
R601
R513-R514 3009561973 RES CF 560 1/5W J N 560
R517 R518
R523-R524
R533-R534
R537 R538
R543-R544
R547-R548
R553 R554
R557 -R558
R577-R578
R603
R604-R606
R588 3009562973 RES CF 5.6K 1/5W J N 5.6K
R515-R516 3009563973 RES CF 56K 1/5W J N 56K
R525 R526
R529 R535
R536
R545-R546
R555-R556
R580
R575 3009683973 RES CF 68K 1/5W J N 68K
R560 R597 3009750973 RES CF 75 1/5W JN 75
R599
R566-R567 3009822973 RES CF 8.2K 1/5W J N 8.2K
VR511 3228070050 VR RV09B-20E1-225F-A14 ALPHA 10KA
VR1-VR2 3228090210 VR RK12K11400A2 10KA(13A)RNF55 10KA
VR501-
VR510
SVR501 3248310220 RES SEMI SR19R 1KB 1KB
C587 3549472407 CAP SPARK KILLER 0.0047UF 400V 0.0047/400
AN504 4353981618 CON SHIELD ASS'Y 6P 420MM
AN502 4355751713 CON ASS'Y 9P 270MM SYS2120
AN501 4355751714 CON ASS'Y 9P 300MM SYS2120 9P
AN503 4355751715 CON ASS'Y 9P 330MM SYS2120 9P
AN508 4355751806 CON ASS'Y 130MM SYS2120 8P
CN508 4428594908 LA5268/LAB0640/2.5MM-08P 8P
CN505 4428595002 LW5267/LWB0640/2.5MM-02P 2P
CN506 4428595003 LW5267/LWB0640/2.5MM-03P 3P
CN702
CN504 4428595006 LW5267/LWB0640/2.5MM-06P 6P
CN507
CN601
CN501- 4428595009 LW5267/LWB0640/2.5MM-09P 9P
CN503
CN606 4428596605 LOCK WAFER LW-1143-05P 5P
CN605 4428596607 LOCK WAFER LW-1143-07P 7P
JK1 JK501 4438001110 JACK PHONE EJU6P 1mV/20Kohm
JK506- 4438098910 JACK PHONE(DAE RYUNG MA-8001) PHONE JACK
JK509
JK502- 4438193610 XLR JACK(F)3P(E203A0031N) 1mV/20Kohm
JK505
TER501 4465997702 SCREW TERMINAL 2P TERMINAL
AM1 FM1 4465998410 ANT SCREW TERMINAL 2T F-CON
SW501 4625996010 SW LEVER SL10020-0203-9P-SN SW/8P
SP1-SP11 4628980610 SW PUSH JPJ112-311DH-01 SW
Ref No.
Part No. ValueDescription
27
Ref No. Part No.
Value
Description
MAIN B’D (4005410100)
