Inter-m SYSTEM-2120 User Manual

SW520 4628988610 SW POWER SDDF3PATL011 (SP278) power
Q502-Q504 2008606104-T TR NPN KTC 3198Y KTC 3198Y
Q506 2008606111-T TR PNP KRA 107M KEC KRA 107M
Q501 2008606998-T TR NPN KTD 1302 KEC ONLY 2SD 1302R
R509 3039561572-F RES MO 560 2W J N 560 2W
C511 C518 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C529
C538-C539
C549 C550
C558-C559
C564 C567
C570
C571-C572
C577 C578
C581-C582
C583 C586
C588
C589-C591
C580 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C574 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50
C561-C562 3409233971-T CAP AF RSG 3.3UF 50V 5 P 3.3/50
C593
C506 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C504-C505 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50
C515-C517
C525-C528
C535-C537
C545-C547
C555-C557
C560 C563
C566 C569
C573 C576
C565 C568 3509101130-T CAP CE SL 100PF 50V J 100P
C594
C502 C507 3509102231-A CAP CE YB 1000PF 50V K AXIAL 1000P
C510 C512
C520-C521
C524 C530
C534 C540
C551
C508 C513 3529100311-A CAP CE SL 10PF 50V J AXIAL 10P
C522 C531
C541
C592 C595 3529103531-A CAP CE F 10000PF 50V Z 0.01u
C584 - C585 3529104531-A CAP CE F 100000PF 50V Z 0.1uF
C548 3529220311-A CAP CE SL 22PF 50V J AXIAL 22P
C509 C514 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
C519 C523
C532-C533
C542-C544
C552-C554
C503 3609102120-T CAP MA 0.001UF 100V 0.001/100(M)
C575 3609103120-T CAP MA 0.01UF 100V 0.01/100(M)
C579 3609104120-T CAP MA 0.1UF 100V J 0.1/100(M)
C501 3609272120-T CAP MA 0.0027UF 100V J 0.0027/100(M)
D2-D3 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D9-D10 2058304100 DIODE IN4148M 1N 4148
D1 2058502030 DIODE ZENER UZ-3.0B A101 3V
IC1 2118011605 IC KIA 7809 API KEC 78L09
IC3 2128110507 IC S3C7335XZ0-QWR5 KS57P33160W
IC4 2128330074 IC IS93C66-3P ISSI A193C66
IC2 2168640984 IC 7806 SAMSUNG 7805
LD4-LD21 2300552110 LED LTL-9233A LITEON GREEN(SLR34URF)
LCD1 2338170398 LCD 8137B1JP SNC60106
F1-F2 2618099930 COIL FM (253AGG-K5001-KR)19KHZ COIL OSC
R37 3009100973 RES CF 10 1/5W J N 10
R20-R23 3009102973 RES CF 1K 1/5W J N 1K
R34
R3-R4 R7 3009103973 RES CF 10K 1/5W J N 10K
R13-R14
R26 R28
R32
R10 3009104973 RES CF 100K 1/5W J N 100K
R24-R25
R31
R9 3009180973 RES CF 18 1/5W J N 18
R5 3009222973 RES CF 2.2K 1/5W J N 2.2K
R8 3009332973 RES CF 3.3K 1/5W J N 3.3K
R15-R16
R11 3009394973 RES CF 390K 1/5W J N 390K
R12 R27 3009472973 RES CF 4.7K 1/5W J N 4.7K
R29-R30
R33 R35
R38 R50
R2 R6 R19 3009473973 RES CF 47K 1/5W J N 47K
R17-R18 3009562973 RES CF 5.6K 1/5W J N 5.6K
R36 3009564973 RES CF 560K 1/5W J N 560K
FE1 3928009999 AM/FM MODULE(KC4-100H) KGT917V/H
AN3 4353980518 CON SHIELD ASS'Y 3P 420MM 3P
AN4 4353981011 CON ASS'Y 4P 230MM 4P
AN6 4353982105 CON ASS'Y 2P 120MM 2P
AN1 4355751414 CON ASS'Y 2P 300MM SYS2120 2P
AN2 4355751514 CON ASS'Y 2P 300MM(2/3) 2120 3P
CN1 CN6 4428595002 LW5267/LWB0640/2.5MM-02P 2P
CN2 4428595003 LW5267/LWB0640/2.5MM-03P 3P
AN5 CN5 4428599008 WAFER YW025-08 YW025-08P
JK1 4465998420 ANT SCREW TERMINAL 2T UL/CSA
4465998410 ANT SCREW TERMINAL 2T Europe
4348000320 WIRE (ANT) FOR AMERICA UL/CSA
4348000330 WIRE (ANT) FOR EUROPE Europe
SW1 4628985710 TACT (5MM) THVV501BAA (KBW89) UP
SW2 4628985710 TACT (5MM) THVV501BAA (KBW89) 4
SW3 4628985710 TACT (5MM) THVV501BAA (KBW89) 3
SW4 4628985710 TACT (5MM) THVV501BAA (KBW89) 2
SW5 4628985710 TACT (5MM) THVV501BAA (KBW89) 1
SW6 4628985710 TACT (5MM) THVV501BAA (KBW89) AM
SW7 4628985710 TACT (5MM) THVV501BAA (KBW89) FM
SW8 4628985710 TACT (5MM) THVV501BAA (KBW89) DOWN
SW9 4628985710 TACT (5MM) THVV501BAA (KBW89) 8
SW10 4628985710 TACT (5MM) THVV501BAA (KBW89) 7
SW11 4628985710 TACT (5MM) THVV501BAA (KBW89) 6
SW12 4628985710 TACT (5MM) THVV501BAA (KBW89) 5
SW13 4628985710 TACT (5MM) THVV501BAA (KBW89) MEMO
SW14 4628985710 TACT (5MM) THVV501BAA (KBW89) ST/MO
Q11 Q16 2008406942-T TR KTC 3192Y KEC C3192Y
Q5 Q10 2008606104-T TR NPN KTC 3198Y C3198Y
Q12
Q2-Q3 Q14 2008606113-T TR PNP KTA 1271(A1515) KEC KTA 1271Y
Q1 Q4 2008606114-T TR NPN KTC103M KEC 103
Q6 Q15
Q8-Q9 2008606998-T TR NPN KTD 1302 KEC ONLY KTD 1302
Q7 Q13 2008606999-T TR KTC 3198BL C3198BL
Q17 2008613955-T TR DTA 124ES A124
R39-R40 3039100472-F RES MO 10 1W 10 1W
R1 3039680575-T RES MO 68 2W J RADIAL 68 2W
C6 C19 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C27 C28
C32
C9 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C4 C36 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50
C8 C10 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C39
C34 3409247147-T CAP SD 470UF 25V 10P 470/25
C13 3509102231-A CAP CE YB 1000PF 50V K AXIAL 1000P
C5 3509103530-T CAP CE F 0.01UF 50V Z 0.01
C7 C11 3509104530-T CAP CE F 0.1UF 50V Z 0.1
C1 3509271231-A CAP CE B 270PF 50V K AXIAL 270P
C2 C31 3509473530-T CAP CE F 0.047UF 50V Z 0.047
C14 3529050311-A CAP CE SL 5P 50V M AXIAL 5P
C17-C18 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
C29 3529560311-A CAP CE SL 56PF 50V J AXIAL 56P
C3-C33 3539223521-A CAP CE YF 22000PF 25V Z AXIAL 22000P
C15 3539472331-A CAP CE YR 4700PF 16V M AXIAL 4700P
C16 3539472331-A CAP CE YR 4700PF 16V M AXIAL 4700P
C30 3609223120-T CAP MA 0.022UF 100V J 0.022(M)
Ref No. Part No. ValueDescriptionRef No. Part No. ValueDescription
28
TUNER B’D (4003483800)
SYS2240 2818093100 TRANS OUTPUT SYS-2240
SYS2240 2828064520 TRANS POWER SYS-2240 220V
AC 220V Version
SYS2240 2828064530 TRANS POWER SYS-2240 230V AC 230V Version
SYS2240 2828064540 TRANS POWER SYS-2240 240V AC 240V
SYS2240 2828064550 TRANS POWER SYS-2240 120V AC 120V
SYS2240 5568223333 BREAKER W28-XQ1A-4A Europe Version
SYS2240 5568223233 CIRCUIT BREAKER W28-XQ1A-6A Europe Version
SYS2120 2818098100 TRANS OUTPUT SYS-2120
SYS2120 2828064620 TRANS POWER SYS-2120 220V AC 220V
SYS2120 2828064630 TRANS POWER SYS-2120 230V AC 230V
SYS2120 2828064640 TRANS POWER SYS-2120 240V AC 240V
SYS2120 2828064650 TRANS POWER SYS-2120 120V AC 120V
SYS2120 5568222933 CIRCUIT BREAKER W28-XQ1A-3A ALL VERSION
POWER CORD 4308997310 AC CORD DOME 3-CORES AC 220V Version
4308999410 AC CORD V+V116A-250VH0VV-F3G Europe
4308996710 AC CORD(WITHOUT PLUG) England
4308998000 AC CORD POWER FOR SAA Australia
4308999310 AC CORD UL 3(INLET) UL/CSA
4355751624 CON ASS'Y 2P 600MM
4355752312 CON ASS'Y 4P 250MM
4355752018 CON ASS'Y 5P 420MM
4355752115 CON ASS'Y 6P 330MM
4355752216 CON ASS'Y 7P 360MM
2058100103 DIODE KBPC-2504
5008988210 SPK UNIT 8 OHM 3W
4355795508 CON ASS'Y 1P Y/G 250 -RING
Ref No. Part No. ValueDescription
29
ASSEMBLE
