Inter-m V-3000 User Manual

PROFESSIONAL POWER AMPLIFIER
11
V-3000/4000
3. OUTPUTS
Bridged Mono operation has a minimum load impedance of 4Ω.
STEREO/PARALLEL CONNECTION
BRIDGED MONO CONNECTION
CHANNEL 2 CHANNEL 1
SPEAKER OUTPUTS
CH1 CH2 BRIDGE
1112 22
POS NEG POS NEG POS NEG
CH2
11
POS NEG
CH2 AMP OUT CH1 AMP OUT
Wiring Using Both Speaker Connectors
Wiring Two Speakers to the Channel 1 Speaker Connector
CHANNEL 2 CHANNEL 1
SPEAKER OUTPUTS
CH1 CH2 BRIDGE
1112 22
POS NEG POS NEG POS NEG
CH2
11
POS NEG
CHANNEL 2 CHANNEL 1
SPEAKER OUTPUTS
CH1 CH2 BRIDGE
1112 22
POS NEG POS NEG POS NEG
CH2
11
POS NEG
Wiring a Speaker in Bridged Mono to the Channel 1 Speaker Connector
