PROFESSIONAL POWER AMPLIFIER
13
V-3000/4000
Specifications
Specifications
* Specifications and design subject to change without notice.
V-3000 V-4000
120VAC 230VAC 120VAC 230VAC
Rated Output Power 8Ω (1kHz, THD 0.1%) 550W 550W 750W 750W
(STEREO) 4Ω (1kHz, THD 0.1%) 1000W 1000W 1300W 1300W
2Ω (1kHz, THD 0.5%) 1600W 1650W 2000W 2100W
Rated Output Power 8Ω (1kHz, THD 0.1%) 2000W 2000W 2600W 2600W
(BRIDGED) 4Ω (1kHz, THD 0.5%) 3200W 3300W 4000W 4200W
Input Sensitivity Rated Power @4Ω 0.95V 1.05V
Voltage Gain @4Ω 36.8dB
Frequency Response (1W @8Ω) 20Hz~20kHz : -0.2dB, 10Hz~100kHz : -3dB
Damping Factor (1kHz @8Ω) more than 400
T.H.D (20Hz~20kHz, 1/10 Power STEREO
less than 0.05%
4Ω, 8Ω & BRIDGED 8Ω)
Channel Separation (1kHz, Half Power @8Ω) more than 70dB
Residual Noise 73dB
Signal to Noise Ratio 105dB 106dB
Output Circuitry 2 Step Class H
Input Impedance 12kΩ Balanced
High Pass Filter (30Hz/50Hz) 12dB/OCT
Indicators Active, Signal, Prot/Clip
Protection Circuitry Full Short Circuit, Thermal Protection
Power ON/OFF Muting, DC Output Protection
Cooling Variable Speed Fans, Front to Rear Air Flow
Connectors Input : XLR(Female), 1/4
TRS, Output : 4 Pole Speaker Socket
Operating Temperature/Humidity Temperature : -10°C ~ +40°C/Humidity : 0%~90%
Power Source 120VAC, 60Hz 230VAC, 50Hz 120VAC, 60Hz 230VAC, 50Hz
Power Consumption (1/8 Power @4Ω) 12 A 6 A 14 A 7 A
Weight (SET) 11.7kg/25.8Ib 11.8kg/26Ib
Dimensions (SET) 482(W) x 88(H) x 407(D)mm/19(W) x 3.5(H) x 16(D)in
