AT235 Additional Information Page 5
2.2 Reflex
Note that in case your protocol has no reflex test included, you can temporarily include a reflex test in your
protocol by pressing the I Reflex C button.
The default displays of reflex tests show a matrix of reflexes, which are measured in the order of appearance
on the screen. The following information is found in the display:
A
The reflex matrix shows graphs of equal stimulus types in the rows and equal stimulus levels in the
columns. Note that scroll bars appear when more stimuli are available than can fit on the screen.
B
Within the graph, the x-axis is the time scale on which the black bar indicates when the stimulus
was given.
C
A green square indicates that the reflex threshold is set (either automatically or manually)at the
chosen stimulus level.
D
The Deflection value is shown when this option is activated through the protocol settings.
E
A grey square indicates a stimulus level that is not available for that particular stimulus type.
F
The square outlined in black indicates which section of the matrix has been selected or is currently
being measured.
Note that the reflexes are indicated by the probe ear. This is shown as an example below.
In the first setup, the probe is placed on the right ear and the contra headphone is placed on the left ear.
