Mount the spacer as described in the following:
Pull the cables through the spacer.
Screw the spacer along with the metal back panel of the IF-57xx to the wall. Recommended installation
height is 1,250 mm.
Fasten the PoE terminal board to the metal back panel of the IF-57xx.
Connect the wires to the PoE terminal board of the IF-57xx.
To keep the IF-57xx master terminal free from interference, we recommend fastening
the spacer in such a way that
§ there is a distance of 30 cm to the next slave terminal or other systems with RFID card readers
§ there is a distance of 10 cm between the connecting cable and the nearest power lines.
18.4.3 Technical Data of the Spacer
Dimension (H x W x D) in mm 230 mm x 121 mm x 22mm
Material Plastic
Color Anthracite NCS7502B (75-5735-0005)
or
Silver RAL 240 70 05 (75-5735-0006)
19 Devices of the Series IF-57xx with WLAN or Camera
Terminals of the series IF-57xx are also available with WLAN or an integrated camera.
§ IF-57xx WLAN
Order Numbers
00-5735-0021 MFP5735 touch, W-LAN, black
00-5735-0022 MFP5735 touch, W-LAN, white
00-5735-0023 LAP5735 touch, W-LAN, black
00-5735-0024 LAP5735 touch, W-LAN, white
00-5725-0024 LAP5725 touch, W-LAN, white
00-5725-0023 LAP5725 touch, W-LAN, black
00-5725-0022 MFP5725 touch, W-LAN, white
00-5725-0021 MFP5725 touch, W-LAN, black
00-5721-0021 MFP5721 Touch, PIN, W-LAN, black
00-5721-0022 MFP5721 Touch, PIN, W-LAN, white
00-5721-0023 LAP5721 Touch, PIN, W-LAN, black
00-5721-0024 LAP5721 Touch, PIN, W-LAN, white
§ IF-5735 with Camera
Order Numbers
00-5735-0031 MFP5735 touch, Kamera, black
00-5735-0032 MFP5735 touch, Kamera, white
00-5735-0033 LAP5735 touch, Kamera, black
00-5735-0034 LAP5735 touch, Kamera, white
