3. Fixing back plate to wall
Flat wall
surface
Use rawlplugs and screws (supplied) to fix back
plate to wall. Use M3 bolts (supplied) to mount back
plate to standard recessed junction box.
4. Wiring thermostat
Insert both wires into connector (either way around).
Ensure wire cross-section is between 0.2 and 0.75 mm².
Connector crimps wires into place automatically.
