Interklima High wall unit
II/IO - SCV1
27
Signal transmitter
Operation display
Auto heat/cool Cooling
Dry Heating Sleep
Fan speed display
Timer display
Timer on Timer off
ON/OFF button
Press once to start operation
Press again to stop operation
Mode selection button
Fan speed selection button
Sleep operate selection button
Timer-on button
Hour adjustment but.
Press to operate
Auto heat/cool
Cooling Dry Heating
Press to operate
Auto Low Middle High
AutoFan Low
Middle High
Aim this side at the receiving signal window of indoor unit
Temperature display
Airflow direction display**
Auto airflow direction
Airflow direction swing
Airflow direction location
Room Temp. Setting button
To adjust the temperature
Airflow direction setting button**
Airflow direction swing setting button**
Timer-off button
Minute adjustment button
**not applicable to ducted type
