ECM20/ECL60 Installation and Operation Manual
TECHNICAL DATA (DATI TECNICI)
Mechanical Caracteristics (Caratteristiche Meccaniche)
Front protection (Protezione frontale): IP65.
Housing (Contenitore): PC+ABS UL94 V-0 resin plastic casing, polycarbonate glass, thermoplastic resin keys
Dimensions (Dimensioni): front 74x32 mm, depth 59 mm. (excluding terminals)
Mounting (Montaggio): panel mounting with 71x29 mm (+0.2/-0.1 mm) drilling template.
Terminals (Morsetti): screw terminal for cable with a diameter of 2,5mm
2
Serial (Seriale): TTL for connection to Copy Card
Temperature (Temperatura): Operating (Utilizzo): –5 … +55 °C - Storage (Immagazzinamento): –30 … +85 °C
Humidity (Umidità): Operating (Utilizzo) / Storage (Immagazzinamento): 10…90 % RH (not condensing)
Electrical Caracteristics (Caratteristiche Elettriche)
Power Supply (Alimentazione): 230Va (+10% / -15%) 50/60 Hz - Consumption (Consumo): 3W max
Display range (Range di visualizzazione): NTC: –50.0°C ... +110°C; PTC: -55.0°C ... +140°C (on display with 3 digits + sign)
Accuracy (Accuratezza): Better than 0.5% of full-scale +1 digit.
Resolution (Risoluzione): 0,1 °C
Buzzer (Buzzer): YES (it depends from the model)
Analogue Input (Ingressi Analogici): ID961: 1 NTC (Default) / PTC input (programmable by parameter H00*)
ID971 e ID974: 2 NTC (Default) / PTC input (programmable by parameter H00*)
Digital Input (Ingressi Digitali): 1 voltage-free digital input
Digital Output (Uscite Digitali) ID961: 1 Compressor relay: IEC 60730-1 15(2)A max 250Va
UL60730 1 Hp (8FLA - 48LRA) max 240Va
ID971: 1 Defrost relay: N.O. 8(3)A - N.C. 6(3)A max 250Va
1 Compressor relay: IEC 60730-1 15(2)A max 250Va
UL60730 1 Hp (8FLA - 48LRA) max 240Va
ID974: 1 Defrost relay: N.O. 8(3)A - N.C. 6(3)A max 250Va
1 Compressor relay: IEC 60730-1 8(3)A max 250Va
UL60730 1/2 Hp (5FLA - 29LRA) max 240Va
1 Fan relay: 5(2)A max 250Va
