ECM20/ECL60 Installation and Operation Manual
Alarms
Max and Min Temperature Alarms
ALARMS
10
Label Fault Cause E ects Remedy
E1
Probe 1 faulty
(cold room)
• measured values are outside
operating range
• probe faulty/short-circuited/open
• Display label E1
• Alarm icon permanently on
• Min/max alarm regulator disabled
• Compressor operation according to “Ont”
parameter.
• check probe type NTC/PTC (H00)
• check the probe wiring
• replace probe
E2
Probe 2 faulty
(defrost)
• measured values are outside
operating range
• probe faulty/short-circuited/open
• Display label E2
• Alarm icon permanently on
• The Defrost cycle will end due to Time out
(Parameter “dEt”)
• check probe type NTC/PTC (H00)
• check the probe wiring
• replace probe
AH1
Probe 1 HIGH
temperature
alarm
• value read by probe 1 > HAL after
time of “tAO”.
(see MAX/MIN ALARMS table)
• Recording of label AH1 in folder AL
• No e ect on regulation
• Wait until temperature value read
by probe 1 returns below HAL
AL1
Probe 1 LOW
temperature
alarm
• value read by probe 1 < LAL dopo
tempo pari a “tAO”.
(see MAX/MIN ALARMS table)
• Recording of label AL1 in folder AL
• No e ect on regulation
• Wait for the temperature value
read by probe 1 to come back
above LAL
EA External alarm
• Digital input activated
(H11 set as external alarm)
• Recording of label EA in folder AL
• Alarm icon permanently on
• Regulation blocked if EAL = y
• to check and to remove the
external cause which generate
alarm on D.I.
Opd Door open alarm
• Digital input activated
(H11 set as door switch)
(for a longer time than tdO)
• Recording of label Opd in folder AL
• Alarm icon permanently on
• Regulator blocked
• close the door
• delay function de ned by OAO
MAX AND MIN TEMPERATURE ALARM
11
Setpoint - LAL
AFd
Off
Setpoint + HAL
AFd
Setpoint - LAL + AFd
Setpoint + HAL - AFd
Setpoint
Temp. ≤ Set+LAL *
Temp. ≥ Set+HAL **
Temp. ≥ Setpoint + LAL + AFd
Setpoint -|LAL|+AFd
Temp. ≤ Setpoint + HAL - AFd
Relative Temperature Value
to setpoint (Att=1)
* if LAL is negative, Set + LAL < Set
** if HAL is negative, Set + HAL > Set
Absolute Temperature Value
(Att=0)
Temp. ≤ LAL (LAL with sign)
Temp. ≥ HAL (HAL with sign)
Temp. ≥ LAL + AFd
Temp. ≤ HAL - AFd
LAL
AFd
HAL
AFd
LAL + AFd
LAL - AFd
Minimum temperature
alarm
Maximum
temperature alarm
Returning from maximum
temperature alarm
Returning from minimum
temperature alarm
