ECM20/ECL60 Installation and Operation Manual
Disclaimer
This manual and its contents remain the sole property of Interlink CONTROLS SRL, and shall not be reproduced or distributed without authorization.
Although great care has been exercised in the preparation of this document, Interlink CONTROLS SRL, its employees or its vendors, cannot accept any
liability whatsoever connected with its use. Interlink CONTROLS SRL reserves the right to make any changes or improvements without prior notice.
Regulations
Electromagnetic compatibility: This device complies with Directive 2004/108/EC and the harmonised standard EN 60730-2-9
Security: This device complies with Directive 2006/95/EC and the harmonised standard EN 60730-2-9
Food safety: This device complies with standard EN 13485 as follows:
- suitable for storage
- climate range A
- measurement class 1 in the range from -35°C to 25°C (*)
(* exclusively using Eliwell NTC probes)
Voluntary marks/certifications: ENEC/UL (check on the device label).
Classification: operating (not safety) device for integration.
NOTE 1: switch the device off and on after modifying the NTC/PTC probe (par. H00).
NOTE 2: check the power supply specified on the instrument label; for relay and power supply capacities,contact the Sales Office.
NOTE:The technical data included in this document, related to measurement (range, accuracy, resolution, etc.) refer to the instrument itself, and not to its equipment such as,
for example, sensors.This means, for example, that sensor(s) error(s) shall be added to the instrument’s one.
Technical Data
Mechanical Caracteristics
Front protection: IP65.
Housing: PC+ABS UL94 V-0 resin plastic casing, polycarbonate glass, thermoplastic resin keys.
Dimensions: front 74x32 mm, depth 59 mm. (excluding terminals).
Mounting: panel mounting with 71x29 mm (+0.2/-0.1 mm) drilling template.
Terminals: screw terminal for cable with a diameter of 2,5mm
2
Connectors: TTL for connection to Copy Card
Temperature: Operating: –5 … +55 °C - Storage: –30 … +85 °C
Humidity: Operating / Storage: 10…90 % RH (not condensing).
Electrical Caracteristics
Power Supply: 230Va (+10% / -15%) 50/60 Hz Consumption: 3W max
Display Range: NTC: –50.0°C ... +110°C; PTC: -55.0°C ... +140°C (on display with 3 digit + sign)
Accuracy: Better than 0.5% of full-scale +1 digit.
Resolution: 0,1 °C.
Buzzer: YES (it depends from the model)
Analogue Input: ECM20: 1 NTC (Default) / PTC input (programmable by parameter H00).
ID971 e ECL60: 2 NTC (Default) / PTC input (programmable by parameter H00).
Digital Input: 1 voltage-free digital input
Digital Output: ECM20: 1 Compressor relay: IEC 60730-1 15(2)A max 250Va
UL60730 1 Hp (8FLA - 48LRA) max 240Va
ID971: 1 Defrost relay: N.O. 8(3)A - N.C. 6(3)A max 250Va
1 Compressor relay: IEC 60730-1 15(2)A max 250Va
UL60730 1 Hp (8FLA - 48LRA) max 240Va
ECL60: 1 Defrost relay: N.O. 8(3)A - N.C. 6(3)A max 250Va
1 Compressor relay: IEC 60730-1 8(3)A max 250Va
UL60730 1/2 Hp (5FLA - 29LRA) max 240Va
1 Fan relay: 5(2)A max 250Va
