Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 143
Note: For expander local devices, select the expander address first, and then
select the local device type.
Press Clear to exit from this view.
Press Enter, then select OK and confirm the new configuration. In this case all
new devices are added, and missing devices are removed from the system.
Note: The second system bus (BUS2) is only available when using the second
RS485 LAN extension module. See also “Two system databuses” on page 23.
2.2 Edit Keypad&Exp
1>Keypad devices
2 Exp devices
Choose what type of device you want to configure.
2.2.1 Keypad devices
Press 0 to add a keypad, or a number to configure an existing one.
Note: The maximum number of devices allowed on the databus is given in
“General features” on page 36.
Keypad options
2.2.1.0 Add keypad
On the Add keypad menu, enter the number for this new keypad and press Enter
to confirm or Clear to exit without adding a device.
After the device is added, the keypad configuration options are shown.
2.2.1.n Select keypad
Select the keypad number to configure.
2.2.1.n.1 Keypad type
The Keypad type screen is an informational screen. The type is defined by
keypad itself.
