Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 145
• You cannot select an area to view and control using this option, if this area is
assigned to a door. To do so, use the menu “5.1.n.6.3 Alarm control” on page
199 instead.
2.2.1.n.3.4 View AG
Provides the same functionality as in “2.2.1.n.3.3 View areas” on page 144, but
for area groups.
See also “Area groups” on page 50.
2.2.1.n.3.5 Control areas
The Control areas menu allows you to select areas that can be controlled by this
keypad. The areas are displayed as a list. To change the selection, press Enter
or Right, and select the appropriate areas.
See also “2.2.1.n.3.3 View areas” on page 144.
2.2.1.n.3.6 Control AG
01-10>Control AG
12.4......
Provides the same functionality as in “2.2.1.n.3.5 Control areas” above, but for
area groups.
See also “Area groups” on page 50.
2.2.1.n.3.7 Control options
1>Card&PIN mode
Card or PIN
The menu contains a set of options connected to the selected keypad control
functions.
See also “Keys” on page 54.
2.2.1.n.3.7.1 Card&PIN mode
1 Card&PIN mode
>Card or PIN<
The Card and PIN mode option allows you to select one of the following control
methods.
• PIN only: Only the PIN is necessary to set and unset areas
• Card only: A single card badge unsets areas
• Card and PIN unset: Both card and PIN are required to unset areas
• Card and PIN always: Both card and PIN are required to set or unset areas
