Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 183
4.1.n.7.1 Pulse count
Set the number of pulses within a time window that will activate the zone.
The following values are applicable:
• 1 to 9: number of pulses within 30 seconds that activates the zone. Only 1
count per second is taken into account.
• 0: the counter functionality is disabled.
4.1.n.7.2 Gross level
Use the Gross level option to set the level for a single pulse that activates the
zone. The following values are applicable:
• 1 to 9: Gross attack level where 1 means high sensitivity, and 9 means low
sensitivity
• 0: Gross level is disabled
Gross level can be checked in menu “1.2.2 ShockSens test” (see page 125).
Wireless sensor options
4.1.n.7 RF details
The RF details menu allows you to program a wireless device manually, or
remove it from the wireless expander.
Note: This menu is only available for a wireless expander ATS1235 with
firmware version 1.13 or newer, which is online.
4.1.n.7.1 Sensor ID
The screen allows you to view the sensor ID.
Note: First two digits of the sensor identifier also define the sensor type. See
Table 26 on page 184.
