Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 185
The following options may be available.
Table 27: Wireless sensor options
Option
Sensor type
Description
Reed and contact
Door/window sensor
Report alarms from both sources
Contact
Door/window sensor
Ignore reed alarms
Reed and shock
Shock sensor
Report alarms from both sources
Shock sensor
Shock sensor
Ignore reed alarms
Reed
Door/window sensor,
shock sensor
Only report reed alarms
Notice tamper
Smoke sensor
Control housing tamper alarms
Ignore tamper
Smoke sensor
Ignore housing tamper alarms
4.1.n.7.6 Remove RF dev
Remove RF dev?
>Cancel<
Select Ok and press Enter to remove the wireless device from the wireless
expander database.
4.2 Areas
1>Area 1
2 Area 2
The Area menu allows you to configure areas and area groups.
See “Areason page 50 in Chapter 3 “System functions” for details.
Each area can be programmed with a number of options, like the area name,
entry and exit times etc. Before going any further, select the area to program.
Area options
4.2.n Select area
1>Area name
Area 1
Select an area to program.
4.2.n.1 Area name
1 Area name
>Area 1 <
Every area can be programmed with a name to identify the area.
