Chapter 5: Menu reference
192 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
4.4.n.3 Buttons
1>Button 1
2 Button 2
Use the Buttons menu to assign an appropriate function to a button or a button
combination.
Note: A user must be assigned in “4.4.n.2 Assigned user” on page 191 for the
button combinations to work.
Table 28 below lists buttons and combinations that are available.
Table 28: Fob buttons and combinations
Buttons
Function
Button 1
Set all areas
Button 2
Unset all areas
Button 3
Part set 1 all areas
Button 4
Toggle trigger 99
Buttons 1 + 2
—
Buttons 1 + 3
—
Buttons 1 + 4
—
Buttons 2 + 3
—
Buttons 2 + 4
—
Buttons 3 + 4
—
4.4.n.3.1 Select button
1>Function
>>>
Select a button to assign a user function to it. See “User programmable
functions” on page 88 for more details.
4.4.n.4 RF details
1>Sensor ID
14232C1
The RF device menu allows you to program a wireless device manually, or
remove it from the wireless expander.
4.4.n.4.1 Sensor ID
1>Sensor ID
14232C1
The screen allows you to view the sensor ID.
