Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 197
The new door is given the default name “Door N” and placed on the end of the
door list. You can now start editing the door details for the new door.
For reader, door zone and lock outputs default addressing, see “Zone, output,
and door addressing” on page 31 in Chapter 2 “Installation”.
5.1.n Select door
Select a door to edit.
The following options can be viewed or configured.
5.1.n.1 Door name
Press Enter to edit the name, or Clear to exit.
The default door name is “Door N”, where N is the door number.
The name can have up to 16 characters.
5.1.n.2 Door location
The read-only screen that shows the physical door location of the selected door.
The door location is shown in the same format as zone location. See “4.1.n.4
Zone location” on page 173.
5.1.n.3 Door readers
The menu allows you to assign entry (IN) and exit (OUT) readers to the selected
door.
Note: Standard doors can only have one IN reader and one OUT reader.
Additional door readers can be only assigned to an intelligent door. For options
related to intelligent doors, see “Intelligent door specific options” on page 204.
The following submenus are available for all doors:
• 1 Reader IN: Select an entry reader
• 2 Reader OUT: Select an exit reader
The following submenus are available only for intelligent doors:
• 3 Reader IN 2: Select an additional entry reader
• 4 Reader OUT 2: Select an additional exit reader
