Chapter 5: Menu reference
208 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
The door remains unlocked as long as the unlock time is counting, or the door
stays closed, whichever is longer. See also “5.1.n.5.1 Unlock time” on page 198.
5.1.n.6.2.3 Pulsed L&UnL
This function is only used on special electronic locks that require two separate
relays to be pulsed at different times for it to open, and two separate zones for
monitoring. If this function is set to Yes, then normal lock-strike opening is
disabled. This option should always be set to No unless otherwise specified.
The functionality is described in details in Chapter 3 “System functions > Pulsed
lock and unlock” on page 71.
5.1.n.6.3.5 User group
1>Installer grp
2 Supervisor grp
Select a user group for the selected door.
See “User groups” on page 62 for details.
5.1.n.6.3.6 Control type
6 Control type
>No control<
Specify what type of alarm control is available for the selected door.
• No control: Reader has no alarm control. It is not possible to set or unset
areas using the readers.
• On 1st badge: Presentation of a valid card at a door reader will unset the
areas in the user group on first badge. Badging three times will set the areas.
• On 3rd badge: Presentations of a valid card three times sets or unsets the
areas in the user group.
• Always: Presentation of a valid card at the IN reader unsets the areas in the
user group. Presentation of a valid card at the OUT reader arms the areas in
the user group.
5.1.n.6.3.7 If PIN sets
Configure the door operation if the area is set using PIN.
5.1.n.6.3.7.1 Deny access
If set to Yes, the access to the door is denied if the areas were set using PIN.
