Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 207
5.1.n.3.5.7 Disable Duress
This option is used to disable duress codes from functioning. If set to Yes, no
duress function is available at this door.
5.1.n.6.1.2 Second zone
The door controller allows the system to monitor two door contacts for a single
intelligent door. Select a second zone with door contact for the selected door. If
there is only one door contact, select No.
See also “5.1.n.6.1.1 Door zone” on page 199.
5.1.n.6.1.3 DOTL zone
Specify the zone that reports the DOTL (door open to long) alarm condition for
the selected door.
Note: DOTL reporting must be enabled in Shunt options. See “5.1.n.6.5.5 DOTL”
on page 210.
5.1.n.6.2 Door unlocked
The menu contains various options for the selected door unlocking process.
5.1.n.6.2.1 Until closed
This option determines when the door will re-lock using the re-lock delay.
• Yes: The door lock will not re-lock until the door is closed. This is used where
the lock mechanism, when locked, will stop the door closing.
• No: The door lock will re-lock (after the unlock time has expired, etc.)
regardless of the door being open or closed.
5.1.n.6.2.2 Until opened
For security reasons, it is possible for the door to re-lock at the moment it opens.
The door stays unlocked until opened, and the door relay is deactivated after the
door opens.
