Chapter 5: Menu reference
210 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
5.1.n.6.5.2 OP&Unl as Unl
If set to yes, the door is reported as unlocked, if it is open and unlocked.
5.1.n.6.5.3 Open/Close
If set to yes, opening or closing door is reported. Otherwise there is no reporting
unless an alarm occurs (depending on the zone type).
5.1.n.6.5.4 Forced door
If set to Yes, opening of the door without a valid card, PIN or Request To Exit is
reported.
5.1.n.6.5.5 DOTL
Report when the door is open too long. If set to Yes and the zone assigned to the
door is in the DOTL state (for example, still open after the shunt timer expires),
the DOTL event is reported.
5.1.n.6.5.6 RTE
If set to Yes, Request To Exit zone activation is reported.
5.1.n.6.6 Interlocking
6 Interlocking
1234567890123456
This menu stipulates the zone numbers on the door controller that prevents the
doors being accessed at the same time. Numbers must be zone numbers on the
same door controller.
To interlock with a door on another door controller, a contact from that door must
be wired to a spare zone on the first door controller, and vice versa. In this case,
if a zone is being used for interlocking and no door on the door controller has that
zone as its “Door Contact”, then the door controller automatically inserts a
2 second delay before a door opens. This is to allow for settling times across the
door controllers. Please remember that this two-second delay only occurs when
a zone is being used for interlocking, and that zone comes from another door not
on this door controller.
