Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 211
To activate or deactivate interlocking, toggle a local zone number.
5.1.n.7.1.2 After entry
Select if the override takes effect immediately the schedule commences, or after
a user has entered.
• Yes: Before the schedule will unlock the door, a user needs to enter the area.
• No: Automatic unlock starts at the schedule start time.
See also “5.1.n.7.1 Door unlocked” on page 201.
5.1.n.7.2 Low Security
Use the menu to configure Low Security functionality of the door. The door low
security mode means that the user authorization is changed from Card and PIN
to Card or PIN.
The following submenus are available:
• 1 Schedule. Select schedules for low security functionality.
The shortcut menu allows you to assign up to two schedules to the selected
element.
See “Schedule shortcut menu” on page 78 for more information.
• 2 RdrIn Inh PIN. If set to yes, the IN reader is in the low security mode if the
above schedule is active.
• 3 RdrOut Inh PIN, etc.
The functionality is configured separately for each door reader. After selecting
the option, choose the appropriate reader, and then set the option value.
5.1.n.7.3 RTE Schedule
Select schedules for Request To Exit input.
The shortcut menu allows you to assign up to two schedules to the selected
element.
See “Schedule shortcut menu” on page 78 for more information.
5.1.n.8.1 Zones
Select zones that must be shunted on the door opening.
