Chapter 5: Menu reference
212 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
To activate or deactivate shunting, toggle a local zone number.
See also “5.1.n.8 Shunt options” on page 201.
5.1.n.8.4 Indication
The menu allows you to assign door controller outputs for indication of the
specific access control events.
5.1.n.8.4.2 DOTL output
Select an output on the door controller to indicate the Door Open Too Long
alarm.
5.1.n.8.4.3 Warning output
Select an output on the door controller to indicate the warning before the shunt
time or extended shunt time expires. See also “5.1.n.8.2 Shunt timers” on page
202.
5.1.n.8.4.4 Forced door
Select an output on the door controller to indicate that the door is forced (opened
without a successful authorization).
5.1.n.8.5 Until door CL
If set to Yes, the door shunt zones remain shunted as long as the door is
opened.
5.1.n.8.6 CancelAfterCL
For security reasons, it may be required to limit the shunt period as much as
possible. If the option is set to Yes, the door shunt zones are shunted until the
door is closed. Opening the door again within the shunt time is not possible, as
this will generate an alarm (there is always a debounce time of approx.
2 seconds).
