Chapter 5: Menu reference
202 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
See also “Door shunt” on page 69 in Chapter 3 “System functions” for shunt
functionality description.
For options specific for standard doors, see “Standard door specific options” on
page 204. For options related to intelligent doors, see “Intelligent door specific
options” on page 204.
5.1.n.8.2 Shunt timers
The menu allows you to configure timers assigned to the door shunt. See details
below.
Note: For standard doors, the timer value is set in minutes and seconds in
mm’ss format, for example, 01’30.
In case of intelligent doors, use two options as submenus:
1. Time: Set the time value from 0 to 127.
2. Resolution: Set units (seconds or minutes) for the time value above.
5.1.n.8.2.1 Shunt time
The amount of time (value and units) for the door zone to be shunted.
5.1.n.8.2.2 Extended time
The extended shunt timer, which is applied if the user has extended time option
enabled. See “3.1.n.8.4 Extended access” on page 167 for details.
5.1.n.8.2.3 Warning time
The warning time is the time period of door shunt warning before shunt time (or
extended shunt time) expires.
Appropriate warning event flags, which are active during this time, can be used
for in user programmable function. See also “User programmable functions” on
page 88, “Zone shunt” on page 53.
5.1.n.8.3 Shunt type
The menu contains parameters that define the effect of the shunt.
