Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 203
For options specific for standard doors, see “Standard door specific options” on
page 204.
5.1.n.8.3.1 Shunting
1 Shunting
>Zone shunting<
The option defines the object of the shunt. The following options are available:
• No shunting. The door is not shunted.
• Zone shunting. The door is shunted. It generates a standard alarm, based on
the zone type settings, if left open longer than the programmed shunt time.
See “5.1.n.8.2.1 Shunt time” on page 202.
• Zone shunting & DOTL. The door is shunted and generates a DOTL (Door
Open Too Long) alarm if it is left open longer than the programmed shunt
time. Enables Forced Door and DOTL to be reported on separate zone
numbers as programmed in “5.1.n.6.5.4 Forced door” on page 210 and
“5.1.n.6.5.5 DOTL” on page 210.
Note: This option is only available for intelligent doors.
• Auto shunting & DOTL. If the area assigned to the door is unset, shunting of
the door commences when the door zone is active (no code or card required).
A DOTL (Door Open Too Long) alarm is generated if it is left open longer than
the programmed shunt time. Forced Door and DOTL are reported on
separate zone numbers as above.
Note: This option is only available for intelligent doors.
5.1.n.10 Move Door
The menu allows you to move the selected door to another physical location. The
new location must be unused.
If the door is moved successfully, the following message appears:
Note: The door name is changed only if it set by default, for example, Door 5
becomes Door 17. If the door has a custom name, it does not change.
This option is only available in a flexible numbering scheme. See “8.7.9 Object
scheme” on page 253 for details.
See also “Zone, output, and door addressing” on page 31.
