Chapter 5: Menu reference
216 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
5.3 Regions
Configure regions.
See Chapter 3 “System functions > Regions” on page 69 for more information.
5.3.0 Add region
Access the menu to add a region. If the region is created successfully, the
following message appears:
The first region is given the name “Outside”, while subsequent regions are
named “Region 2”, “Region 3”, etc.
5.3.n Select region
Select a region to program.
5.3.n.1 Region name
1 Region name
>Region 2 <
Every region, except region 1 “Outside”, can be programmed with a name to
identify it.
Use the Region name screen to enter or change the region name. The name can
contain up to 16 characters.
5.3.n.2 Delete region
To remove a region, select a region using the cursor, or by entering the region
number, and go to the Delete region menu.
The display shows:
Choose Ok and press Enter. This deletes the region.
Repeat the command to delete other regions, or press Clear to exit and return to
the higher menu level.
Note: You cannot delete region 1.
