Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 217
6 Outputs and filters
In this programming section outputs, filters and triggers, and their options are
programmed. Outputs on panel or expander as well as system triggers can be
activated.
6.1 Condition filters
0>Add filter
1 External Siren
A condition filter is an evaluation and a decision-making algorithm. There are 64
pre-programmed filters.
Filter settings
6.1.0 Add filter
Access the Add filter menu option to add a condition filter. If the filter is created
successfully, the following message appears:
The new filter is given the default name “Filter N” and placed on the end of the
condition filter list. You can now start editing its details.
6.1.n Select filter
Select an existing filter to program.
6.1.n.1 Filter name
1 Filter name
>Filter 52 <
The name identifies the filter for installer, making the programming dependencies
clearer.
6.1.n.2 Formula
0>Add event
----------------
The Formula menu allows definition of the filter formula. Up to 4 events can be
combined in a formula.
