Chapter 5: Menu reference
218 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
6.1.n.2.0 Add event
Use the Add event command to add an operand to the current formula. Press
Add event to add the operand.
This menu entry is not available if the formula already contains 4 events.
The next steps depend on whether you select an event or an operator for the
formula.
6.1.n.2.x Select event
Select the appropriate event to configure it.
To choose an appropriate event, you must define the source of the event first.
The source is defined by a group of objects, and an object within this group.
Available groups are listed in Appendix A “Advisor Advanced events” on page
311.
When the group and the object (if available) are selected, select the appropriate
event. The available selection depends on the selected source. The full event list
with sources is shown in Appendix A “Advisor Advanced events” on page 311.
The following functions are available for the selected event:
1. Group: Select group
2. Element: Select an element (or all elements) from the group above
3. Event: Select an event for the element above
4. Invert: Invert the selected event. If inverted, it is marked with '!' in the formula
5. Remove event: Remove the selected event
6.1.n.2.y Select operator
All events are joined with logical operators. Choose the operator to change it.
Valid operators are AND, OR, and XOR.
6.1.n.3 Invert
The Invert option specifies if the condition filter output is inverted.
6.1.n.4 Delete filter
Use the screen to remove a condition filter from the system. To remove the filter,
select OK and press Enter again. The filter is deleted.
