Chapter 5: Menu reference
220 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
6.2.n.2 Output location
The Output location is a read-only field that is a physical identification of the
output in a format “<device> <y>.<z>”, where <device> can be a panel, an
expander, or a keypad, <y> is the device number, and <z> is a device output
number.
6.2.n.3 Invert output
The Invert output option determines if the output is inverted.
6.2.n.4 Start filter
00>Not used
01 Internal Sire
Use the Start filter menu to specify a condition filter that activates the output. The
output behaviour depends on the output activation mode, described in “6.2.n.6
Mode” below.
6.2.n.5 Stop filter
00>Not used
01 Internal Sire
Use the Stop filter menu to specify an optional condition filter that deactivates the
output.
6.2.n.6 Mode
The following modes are available:
• Follow: The output state is equal to the start condition filter state, unless the
stop conditional filter becomes valid.
The start of the output activation depends on the delay programmed in
“6.2.n.7.1 Delay time” on page 222.
If the delay is programmed to 0, the output activates immediately. Otherwise,
the output activates only after the start condition filter has been active for the
time programmed.
When the stop condition filter activates, the output immediately becomes
passive.
