Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 255
8.8.3 System tamper areas
3 SysTamp areas
>1.......<
The System tamper areas option allows assigning system tampers and faults to
the specified areas. At least one area must be selected.
8.8.4 Siren retrigger
If there are multiple alarms, and the Siren retrigger option is set to Yes, the
external siren activates every time an alarm occurs. Otherwise, the external siren
activates only after the first alarm.
8.8.5 Card learn-in
5 Card learn-in
>Keypad 1<
Choose a keypad for user card learning. See also “3.1.n.3 User card” on page
163.
8.8.6 Test inputs
The Test inputs option defines what inputs should be accessible when
performing input tests as described in “1.2.1 Input tests” on page 121. The
following options are available:
• All: All inputs are visible.
• If used: Only the inputs assigned to the existing zones are visible.
8.8.7 Buzzer mode
7 Buzzer mode
>Continuous<
The Buzzer mode menu defines how the keypad buzzer works during the exit
time. The following options are available:
• Continuous: The keypad buzzer emits a continuous sound that switches to an
intermittent during an entry/exit or access zone activity.
• Intermittent: The keypad buzzer emits a continuous sound and switches to an
intermittent 10 seconds before the exit time expires.
