Chapter 5: Menu reference
264 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
9.1.n.4.2 Dest port
The destination port is used to report to the host selected in “9.1.n.4.1 Dest
name” on page 263.
9.1.n.4.3 Ping host
The Ping host command allows you to send a ping to the selected central station.
This command is used to check if the central station is present and accessible
from the panel in the network.
The Tx/Rx value indicates a number of packets sent and received.
Note: Monitoring station can be configured to not respond to ping requests, thus
this feature may not work with every CS IP address. To test the communication
path, use menu “1.2.7.n.2 Ping host” described on page 132 to send ping to
another host.
9.1.n.8.3 OH 2000
The OH 2000 menu allows you to set up a few OH 2000 protocol options that are
listed below.
9.1.n.8.3.1 Version
The following versions of the OH 2000 protocol can be used for Osborne-
Hoffman receiver communication:
• OH V1.9.3
• OH V2
• OH V3
See an appropriate receiver’s manual for more details.
9.1.n.8.3.2 Heartbeat time
2 Heartbeat time
>00:01’00<
The heartbeat time defines how often the panel sends a presence message
(heartbeat) to the central station. The range for this value is from every second
(00:00’01) to every day (23:59’59). The maximum value 23:59’59 means the
heartbeat functionality is disabled.
