Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 265
9.1.n.8.3.3 Receiver nbr
A receiver identifier used in central stations with multiple receivers. The allowed
value is a hexadecimal number from 0001 to FFFF.
9.1.n.8.3.4 Line nbr
A line identifier used in central stations with multiple receiving lines. The allowed
value is a hexadecimal number from 0001 to FFFF.
9.1.n.8.3.5 Freq. HB time
5 Freq. HB time
>00:01’00<
If the primary CS communication fails, the backup CS heartbeat time is switched
from normal to frequent.
See also “9.1.n.8.3.2 Heartbeat time” on page 264.
Photo transmission specific options
Additionally to “IP and GSM/GPRS specific options” described on page 263, it is
necessary to set the options below.
9.1.n.4.4 Encryption
If the Encryption option is set to Yes, the pictures are sent encrypted with AES
algorithm.
9.1.n.4.5 Vid dest port
The destination port is used to send the pictures to a host set up in “9.1.n.4.1
Dest name” on page 263.
GSM/phone specific options
9.1.n.4 Destination
The Destination menu contains the configuration of the reporting receiver.
