Interlogix ATS3500A-IP-MM Installation And Programming Manual

Appendix A: Advisor Advanced events
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 323
Group
Event
#
Event description
Notes
Low sec.inside
12
Door low security
inside
Card or PIN required to access
at the "IN" reader
Low sec.outs.
13
Door low security
outside
Card or PIN required to access
at the "OUT" reader
Anti-passback
14
Anti-Passback is active
Door shunting
15
Shunt timer is running
Shunt warning
16
Shunt warning timer is running
D. Area armed
17
Area assigned to the door is
armed. As a macro output, this
event disables a door when
"Deny access when set" is set to
Yes.
Keypad duress
18
Duress PIN entered at door
keypad
DOTL
19
Door contact is active after
shunt timer has expired
Forced
20
Door contact is active with no
valid door command
LED 1
21
LED 1 output is active
LED 2
22
LED 2 output is active
Buzzer
23
Door buzzer output is active
Group
Event
#
Event description
Notes
Door
access
Interlock
1
Interlock zones are active
Intlck.overrid
2
Interlock has been overridden
Denied
3
Door access has not been
allowed
Granted
4
Door access has been allowed
Granted traced
5
Door access has been granted
to a user with trace On
Granted 1badge
6
Door access has been granted
when badged once
Granted 2badge
7
Door access has been granted
when badged twice
Granted 3badge
8
Door access has been granted
when badged three times
Granted IN btn
9
Door access has been granted
and IN button pressed
Granted OUTbtn
10
Door access has been granted
and OUT button pressed
Fire override
11
Secondary override is active
Normal
12
The door is locked and closed.
