Chapter 3: System functions
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 93
If next zones are already occupied on the wireless expander, the learning
process is over.
Proceed with the zone configuration.
Manual mode
In manual mode, you can learn and configure a wireless sensor.
To learn a sensor in manual mode:
1. Go to the “4.1.0 Add zone” menu described on page 171.
1>Expander 1
2 Expander 2
2. Select zone location.
3. Choose Manual mode and press Enter.
Tamper RF 1
Press # for ID
4. Activate the device, or press Enter to enter the wireless device identifier
manually. See “Device activation” on page 97 for more information about
activation.
Note: Learning a wireless PIR camera by entering its identifier is not
supported.
The sensor ID is printed on a barcode sticker on the sensor box in the
following format: “Tx H<nnnnnnn>”. For example, “Tx H103EB2B” mark
identifies a sensor with the ID 103EB2B. See also “4.1.n.7.1 Sensor ID” on
page 183 for more details on sensor identification.
If the input has been already programmed, you are informed by a message and
seven beeps.
Next you are asked if you want to replace the programmed wireless device.
Note: If the programmed device has two inputs capacity, the system asks should
the device occupy two zones. See “Two-zone RF sensors” on page 96.
