Interlogix Concord 4 RF - Eight Supervised Inputs for Various Hardwired Detectors. Zone

8 Concord 4 Installation Guide
Number
Name
Application
Alarm
Delay
Restoral
Supervisor
y
CS
report
Chime
(level)
Active
(level)
19
Delayed
interior
Interior doors that initiate a delay
before going into alarm
1
Police
Interior
X
X
X
3
20
Delayed
interior
PIR motion sensors that initiate a
delay before going into alarm
1
Police
Standard
X
X
3
21
Local instant
interior
24-hour local alarm zone protecting
anything that opens and closes
Police
Instant
X
X
1, 2, 3
22
Local
delayed
interior
Same as group 21, plus activation
initiates a delay before going into
alarm
Police
Standard
X
X
1, 2, 3
23
Local instant
auxiliary
24-hour local alarm zone protecting
anything that opens and closes
3
Auxiliary
Instant
X
X
1, 2, 3
24
Local instant
auxiliary
24-hour local alarm zone protecting
anything that opens and closes,
sirens shut off at restoral
1
Auxiliary
Instant
X
X
1, 2, 3
25
Local
special
chime
Notify the user w hen a door is
opened, sounds emit from a local
annunciator
1
Special
chime
Instant
X
1, 2, 3
26
Fire
24-hour fire, rate-of-rise heat, and
smoke sensors
Fire
Instant
X
X
X
1, 2, 3
27
Output
module
Hardw ired output module (HOM)
lamp control or other customer
features
3
Silent
Instant
X
X
1, 2, 3
28
Output
module
HOM, PIR motion sensor, sound
sensor, or pressure mat
3
Silent
Instant
X
1, 2, 3
29
Auxiliary
Freeze sensor
Auxiliary
Instant
X
X
X
1, 2, 3
32
Output
module
HOM, PIR motion sensor, sound
sensor, or pressure mat
3
Silent
Instant
1, 2, 3
33
Siren
Wireless siren supervision
Silent
Instant
X
X
1, 2, 3
34
Gas
Carbon monoxide (CO) gas
detectors
3
Auxiliary
Instant
X
X
X
1, 2, 3
35
Local instant
police (day
zone)
Local alarm levels 1 and 2, report to
CS in level
3
Police
Instant
X
X
X (level 3
only)
1, 2, 3
38
Auxiliary
Water sensor
3
Auxiliary
Instant
X
X
X
1, 2, 3
1. This group is not certified as a primary protection circuit for UL-listed systems and is for supplementary use only.
2. Sound instant police siren if tw o or more sensors are tripped w ithin 4 minutes. Otherw ise sensors are followers to delayed sensors. If
Alarm Verification is on, group 18 functions like group 17.
3. This group has not been investigated by UL.
4. This group is required for UL-listed residential fire alarm applications.
5. Does not satisfy Auto Stay Arming exit requirement.
