LOC PG DESCRIPTION DEFAULT YOUR DATA
267 14
DAYS FOR SCHEDULE 7
1 = “On” if schedule is active on Sunday.
2 = “On” if schedule is active on Monday.
3 = “On” if schedule is active on Tuesday.
4 = “On” if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
268 14
OPENING TIME FOR SCHEDULE 8
Seg 1 Hour of Opening Time (24-hr format) 8 = 8 AM
Seg 2 Minutes after Hour of Opening 0
269 14
CLOSING TIME FOR SCHEDULE 8
Seg 1 Hour of Closing Time (24-hr format) 20 = 8 PM
Seg 2 Minutes after Hour of Closing 0
270 14
DAYS FOR SCHEDULE 8
1 = “On” if schedule is active on Sunday.
2 = “On” if schedule is active on Monday.
3 = “On” if schedule is active on Tuesday.
4 = “On” if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
271 15 HOLIDAYS IN JANUARY (8 max) No holidays
_ _ _ _ _ _ _ _
272 15 HOLIDAYS IN FEBRUARY (8 max) No holidays
_ _ _ _ _ _ _ _
273 15 HOLIDAYS IN MARCH (8 max) No holidays
_ _ _ _ _ _ _ _
274 15 HOLIDAYS IN APRIL (8 max) No holidays
_ _ _ _ _ _ _ _
275 15 HOLIDAYS IN MAY (8 max) No holidays
_ _ _ _ _ _ _ _
276 15 HOLIDAYS IN JUNE (8 max) No holidays
_ _ _ _ _ _ _ _
277 15 HOLIDAYS IN JULY (8 max) No holidays
_ _ _ _ _ _ _ _
278 15 HOLIDAYS IN AUGUST (8 max) No holidays
_ _ _ _ _ _ _ _
279 15 HOLIDAYS IN SEPTEMBER (8 max) No holidays
_ _ _ _ _ _ _ _
280 15 HOLIDAYS IN OCTOBER (8 max) No holidays
_ _ _ _ _ _ _ _
281 15 HOLIDAYS IN NOVEMBER (8 max) No holidays
_ _ _ _ _ _ _ _
282 15 HOLIDAYS IN DECEMBER (8 max) No holidays
_ _ _ _ _ _ _ _
283 15 ACTIVATION DATA FOR USER CARDS 1 - 120
1 = User Cards 1 – 8
2 = User Cards 9 – 16
3 = User Cards 17 – 24
4 = User Cards 25 – 32
5 = User Cards 33 – 40
6 = User Cards 41 – 48
7 = User Cards 49 – 56
8 = User Cards 57 – 64
9 = User Cards 65 – 72
10 = User Cards 73 – 80
11 = User Cards 81 – 88
12 = User Cards 89 – 96
13 = User Cards 97 – 104
14 = User Cards 105 – 112
15 = User Cards 113 – 120
LED1 = Card 1
LED2 = Card 2
LED3 = Card 3
LED4 = Card 4
LED5 = Card 5
LED6 = Card 6
LED7 = Card 7
LED8 = Card 8
NX-1701E Installation manual Page 21 31/01/05
