LOC PG DESCRIPTION DEFAULT YOUR DATA
258 14
DAYS FOR SCHEDULE 4
1 = “On” if schedule is active on Sunday.
2 = “On” if schedule is active on Monday.
3 = “On” if schedule is active on Tuesday.
4 = “On” if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
259 14
OPENING TIME FOR SCHEDULE 5
Seg 1 Hour of Opening Time (24-hr format) 8 = 8 AM
Seg 2 Minutes after Hour of Opening 0
260 14
CLOSING TIME FOR SCHEDULE 5
Seg 1 Hour of Closing Time (24-hr format) 20 = 8 PM
Seg 2 Minutes after Hour of Closing 0
261 14
DAYS FOR SCHEDULE 5
1 = “On” if schedule is active on Sunday.
2 = “On” if schedule is active on Monday.
3 = “On” if schedule is active on Tuesday.
4 = “On” if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
262 14
OPENING TIME FOR SCHEDULE 6
Seg 1 Hour of Opening Time (24-hr format) 8 = 8 AM
Seg 2 Minutes after Hour of Opening 0
263 14
CLOSING TIME FOR SCHEDULE 6
Seg 1 Hour of Closing Time (24-hr format) 20 = 8 PM
Seg 2 Minutes after Hour of Closing 0
264 14
DAYS FOR SCHEDULE 6
1 = “On” if schedule is active on Sunday.
2 = “On” if schedule is active on Monday.
3 = “On” if schedule is active on Tuesday.
4 = “On” if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
265 14
OPENING TIME FOR SCHEDULE 7
Seg 1 Hour of Opening Time (24-hr format) 8 = 8 AM
Seg 2 Minutes after Hour of Opening 0
266 14
CLOSING TIME FOR SCHEDULE 7
Seg 1 Hour of Closing Time (24-hr format) 20 = 8 PM
Seg 2 Minutes after Hour of Closing 0
NX-1701E Installation manual Page 20 31/01/05
