2 TruPortal IP-based Single Door Controller Quick Reference
Setting the DIP Switches
Set DIP switches before installing and wiring readers. See Figure
10 on page 7 for switch locations.
The following table provides switch settings for input types:
Note: After changing DIP switch settings to modify input types,
be sure to reboot the IPSDC.
Switches SW4—SW7 are right-angle, momentary-contact push
buttons described in the following table and shown in Figure 11 on
page 8.
Note: The reader board address is internally set to Address 1.
Connecting the Readers and Inputs
Use Figure 10 on page 7 to wire the readers and inputs. Refer to
the reader documentation for wiring instructions.
Note the following details:
• IPSDCs do not support the following TruPortal features:
Buzzer actions initiated by action triggers, auxiliary inputs/
outputs, and reader tamper inputs.
• The reader DI port (J2) has two digital inputs which are used
for door status devices (door contacts and exit request input).
The inputs can be configured as supervised or non-
supervised. Inputs configured as supervised digital inputs
require End-of-Line (EOL) resistors.
• The reader interface has built-in pull-up resistors to
accommodate cable lengths over 500 feet (152.4 meters). No
external pull-up resistors are required for the reader interface.
Note: A TruPortal IPSDC Power Requirement Wattage
Calculator is included on the product disc in the
\Documentation\en-US folder for use in determining
peripheral loads.
Switch Purpose
SW1 – Select Custom
Wiegand Card Format
[1]
1. Use the System Administration > Card Formats page
in the TruPortal User Interface to configure Wiegand
card formats.
Set SW1-1 to OFF and set SW1-2 thru
SW1-4 to ON.
SW2 Set all four DIP switches to OFF
SW1-5 and SW1-6 SW1-7 SW1-8
Supervised DI/REX 1,
4-State
N/A ON N/A
Supervised DI/REX 1,
2-State (default)
N/A OFF N/A
Switch Purpose
SW4 – Boot Mode Manually enables the ICT. See the TruPortal
Software User Guide for details.
SW5 – Hardware Reset Reboots the IPSDC. Use this switch only if
performing a controlled manual shutdown, as
instructed by Technical Support.
SW6 – Shutdown Request See Safe Shutdown Procedure on page 5.
SW7 – Restore Defaults Press SW7 for a minimum of five (5) seconds,
then release to return the configuration to factory
default settings:
Primary Connection Type: Ethernet
IP Address: 192.168.6.6
Subnet Mask: 255.255.255.0
Gateway: 192.168.6.1
Table 1: Maximum Peripheral Loads
Reader/Strike PoE Auxiliary Power Supply
Voltage (DC) 12 24 12 24
Total watts available 8 10 12 20
Table 2: Device Current
Device
Operating
Voltage
Average
Measured
Current (mA) Watts
T-100 reader 12 55 .66
T-200 reader 12 55 .66
T-500 reader 12 95 1.14
T-520 reader 12 105 1.26
T-525 reader 12 140 1.68
Securitron M62 Magnalock
strike
[1]
1. When using magnetic strikes with auto-voltage select, addi-
tional power allowances must be considered due to auto-
voltage circuitry operation.
12 240 2.88
Securitron M62 Magnalock
strike
[1]
24 140 3.36
HES, Inc 5000-12/24D strike 12 230 2.76
HES, Inc 5000-12/24D strike 24 115 2.76
Rutherford 4114x05x32D strike 12 190 2.28
Von Duprin 5100 3FP695
12 VDC
12 290 4.68
Von Duprin 5100 3FP695
24 VDC
24 195 4.68
RCR-REX 12 28 0.34
RCR-REX 24 17 0.41
